Confirm the verification by pressing the Verify button after the correct measuring system function
has been validated and the configuration data have been verified by the user. The configuration data
are now considered verified. This is visually indicated by the tick in the SCID verified checkbox.
The configuration data can now be locked to protect them from unintentional changes.
The measuring system must always be locked after the configuration data have
been verified.
To do so, set a password. This relates to locking and unlocking a configuration.
A 16-character password can be set in the Password: field of Lock/Unlock the configuration
section. The assigned password must be re-entered in the Confirmation: field to confirm the
password. If no password protection is required, the configuration can be locked with the standard
password (no entry).
The Lock button locks the current configuration. The configuration cannot be changed in this state.
Now, the configuration can only be changed with the correct password (if assigned) and by unlocking
it via the Unlock button or by resetting the measuring system to the factory settings.
The signature can only be considered verified after a user test and a completed
configuration.
Now, the safety-related configuration is complete, the measuring system can be integrated into the
CIP Safety™ network, and connections to the originators can be established with the Type 2
SafetyOpen configuration options.
The user must ensure the originator and measuring system are correctly configured
when a safety connection of the measuring system has been configured wi
safety configuration ID SCID = 0
. However, we strongly advise against this
operating mode, as it bypasses an automated security check.
4.6 Commissioning via SCHNEIDER M580 SIL3 (BME P58) – Type 2
Download, technical information: www.tr-electronic.de/f/TR-ECE-TI-DGB-0363
4.7 Commissioning via Allen-Bradley Compact GuardLogix 5370 – Type 1
Download, technical information: www.tr-electronic.de/f/TR-ECE-TI-DGB-0370
