General Status Code Name Description
0x24 Message Format Error
The server does not support the format of the
received message.
0x25 Key Failure in path
The key segment (included as the first segment in
the path) does not match the target module. The
object-specific status indicates the defective part.
0x26 Path Size Invalid
The path size sent with the service request is
either not large enough to enable the service or
too much routing data have been added.
0x27
Unexpected attribute in
list
An attempt was made to set an attribute which
cannot be set at that moment.
0x28 Invalid Member ID
The Member ID specified in the request does not
exist in the specified class / instance / attribute.
0x29 Member not settable
An attempt was made to write to a read-only
member.
12.3 Miscellaneous faults
Fault Cause Solution
Position jumps of the
measuring system
strong vibrations
So-
called “shock modules dampen vibrations,
impacts, and shocks, e.g. on presses. The
measuring system must be replaced if this
error reappears despite these measures.
electrical interference,
EMC
Isolated flanges and couplings made of plastic
may help against electrical faults, as well as
cables with twisted pair wires for data and
suppl
y. Shielding and cable routing must
follow the installation guidelines and the
specification.
extreme axial and radial
load on the shaft or a
scanning defect.
Couplers prevent mechanical stress on the
shaft. If the error occurs repeatedly despite
these measures, the measuring system must
be replaced.
