16
Southwestern Industries, Inc.
TRAK KMX Knee Mill, Bed Mill & ProtoTRAK KMX CNC Retrofit Safety, Programming, Operating & Care Manual
TRAK K3KMX
Table Size
50" X 10"
Table Travel
32"
Saddle Travel
16"
Knee Travel
16"
Ram Travel
15"
Maximum Quill Travel
5"
Quill Diameter
3.375"
Spindle Taper
R8
Spindle Speed
Vari-speed head
60-500, 600-4200 RPM
Head Tilt
45° forward and back, 90° left and right
Quill Feeds per Rev
0.0015", 0.003", 0.006"
Spindle Motor Power-Vari-speed
3HP
Power Requirement Control
110V, 1P, 10A
Power requirements, machine
220/440V, 3P, 8.5/4.25A
Maximum Weight on Table
750 lbs.
Machine Weight
2816 lbs.
Machine dims: L, W, H
71" x 59" x 84"
Max rapid feed X, Y
100 IPM
Way surface type
Dovetail X, Z, Square Y
• Precision 7207 CP4 spindle bearings
• Chrome hardened and ground quill
• Meehanite castings
• Slide ways are Turcite coated
• Wide way surfaces are hardened and ground
