TRAK K3KMX - Default Chapter; Table of Contents

i
Southwestern Industries, Inc.
TRAK KMX Knee Mill, Bed Mill & ProtoTRAK KMX CNC Retrofit Safety, Programming, Operating & Care Manual
Table of Contents
1.0 Introduction 1
1.1 Models 1
1.2 Manual Organization Notes 2
2.0 Safety 3
2.1 Safety Publications 3
2.2 Danger, Warning, Caution, and Note Labels and Notices As Used In This Manual 3
2.3 Safety Precautions 6
3.0 Description 8
3.1 ProtoTRAK KMX CNC Specifications 8
3.1.1 Basic System Specifications 8
3.2 Display Pendant 10
3.2.1 Front 10
3.2.2 Pendant Back Panel 12
3.2.3 Servo Motors/Amplifiers 13
3.2.4 Ballscrews 13
3.3 TRAK Knee Mill Specifications 14
3.3.1 Manual Lubrication System – K3KMX 17
3.3.2 Auto Lube System – K3KMX Option 17
3.3.3 Electrical Cabinet (TRAK Knee Mills Only) 18
3.4 Optional Equipment 19
3.4.1 Power Draw Bar 19
3.4.2 Remote Stop Go Switch 19
3.4.3 Work Light (TRAK Knee Mills Only) 19
3.4.4 Coolant Pump (TRAK Knee Mills Only) 19
3.4.5 Spray Coolant (TRAK Knee Mills Only) 19
3.4.6 Chip Pan (TRAK Knee Mills Only) 19
3.4.7 Table Guard (TRAK Knee Mills Only) 19
3.4.8 USB Thumb Drive 19
3.4.9 Electronic Handwheels 20
3.4.10 Position Encoders 20
3.4.11 Limit Switches 20
3.4.12 Cable Breakout Box 20
3.4.13 Offline Programming 20
4.0 Basic Operation 21
4.1 ProtoTRAK KMX Basic Operation. 21
4.1.1 Switching the ProtoTRAK KMX CNC on and off 21
4.1.2 Screen saver 21
4.1.3 Switching Between two and Three-Axis Operation 21
4.1.4 Modes 21
