G80
X
X
Canned cycle cancel
G81
X
X
Drill cycle, counter boring
R=rapid position, Z=final depth
G82
X
X
Drilling cycle with dwell
P=dwell time in milliseconds
G83
X
X
Peck drilling cycle
Q=depth of peck, I=depth of
first cut, J=amount per peck,
K=min cut
G85
X
X
Boring cycle
G89
X
X
Boring cycle with dwell
See G82
G90
X
X
Absolute mode
Default
G91
X
X
Incremental mode
G98
X
Use previous Z position as
rapid plane
Default
M-Code
.GCD
.CAM
Description
M00
X
X
Program stop – press GO to proceed
M02
X
X
End of program (no rewind)
M05
X
End of program
M06
X
X
Tool change
M08
X
Coolant on
M09
X
Coolant off
M12
X
Indexer pulse at beginning of event
M20
X
Indexer pulse at end of event
M21
X
Indexer pulse
M30
X
End of program (rewind stop)
M333*
X
Enable low pass filter
M334*
X
Disable low pass filter - default
*The low pass filter is used for applications where higher blocks per second performance is
desired, such as for surfacing programs. It will look ahead more blocks of G-code, and blend
moves together to achieve smoother motion. Note that when enabled, sharp corners may be
rounded off at higher feedrates. When running event programs the KMX runs with this option
disabled.
12.9 Networking
By default, the ProtoTRAK KMX control is set to look for part programs on the first
removable USB flash drive that is available. However, this can be changed to a network
location by using service code 345. To access this from the MODE screen, press SET
UP, followed by SERV CODES soft key, and then type in 345 and press ABS SET.
