14.0 Service Codes
Service codes are special codes used for set-up, installation, program file transfer
and service.
For Service Codes press MODE, SET-UP and SERVICE CODES.
Press A for Software Codes. Input the code number and press SET.
Software, Firmware and PLC
versions
Displays current software versions and system
settings.
Load configuration file from
USB thumb drive
To load configuration files from a USB thumb
drive to the KMX control.
Save configuration file to
USB thumb drive
To save the configuration files for reloading
later. When a computer replacement is
necessary, saving the settings to a thumb drive
for reloading them later is highly desirable.
Runs the routine that copies new software from
a USB thumb drive device to the ProtoTRAK
system. Use this routine to install new
ProtoTRAK software.
Press B for Machine Codes. Input code number and press SET.
Measures the backlash between motor
encoders and glass scales.
Measures the friction characteristic of the
machine.
It allows the user to set the positive direction
for each axis.
Axis Calibration Using Offset
This is a scale factor (one per axis) that is
defined as the length of the part programmed
divided by the physical dimension of the actual
part measured. It is less than 1 for a part that
was cut too big and greater than 1 for a part
that was cut too small.
Use to calibrate the KMX control with a
standard
Backlash Calibration Constant
Use to load backlash compensation for each
axis.
Toggle X Sensor/Glass Scale
On or Off
Toggle Y Sensor/Glass Scale
On or Off
Change direction of EHW on X axis
Change direction of EHW on Y axis
