Toggle Limit Switches On or
Off
Turns limit switches on or off
Reverse Y Position Sensor
Reverse the direction of the sensor or glass
scale
Reverse X Position Sensor
Reverse the direction of the sensor or glass
scale
Reverse Quill Position Sensor
Reverse the quill sensor or glass scale. Service
code 97 should do the same.
Toggle Limit Switches from 1
to 2 input
Tells software which style limit switch is
present.
Turns the EHW option on or off since EHW are
optional.
Update Foreign Language
MLS File
Used to update the software language table.
Please contact your distributor for available
languages and for more information.
Press C for Diagnostic Codes. Input code number and press SET.
Program, Configuration File,
Log Back up
The following service code captures all
important data from the 2 OP machine. This
includes the users program, configuration files,
message log, fault log etc. This is meant to be
used to help us solve problems that may
pertain to our software. This file can then be
emailed to our service department.
Cycles through the program in current memory.
Program Panel Keyboard Test
Gives a tone feedback to a button push and
highlights the button.
Run an axis at rapid speed for 1 second to
check encoders
Turns off servos so you can check encoders
Electronic Handwheel Test
Logs the machine as it runs. It captures all key
presses, error messages and data as the
machine runs. It is saved automatically with
service code 1.
A log that captures all faults and error
messages.
Displays error messages on screen
Displays memory availability of various devices
Turns on and off some test lights used for
troubleshooting blocks per second problems.
Check Control IO
(input/output)
Application used to check all machine input and
outputs.
Note – may not be available on first
release of software
