TK 55711-19-OP-EN
39
Electrical Control System
TriPac Control System Voltage 12 Vdc (powered from tractor’s batteries)
Fuses
Refer to (“Fuses,” p. 39)
Power Inverter 1100 to 1800
Watts (Option)
12 Vdc to 120 Vac (1100 to 1800 Watts depending on
model)
Fuses
Fuse Number Amp Rating Component Protected / Circuit -
Connector
F1 30 Starter
F2 2 HMI Controller
F3 30 Glow Plugs
F4 2 HMI Controller
F5 5
Standby Switch (Option)
F6 5 Logic Power (Main Controller)
F7 40 Fuel Solenoid
F8 7.5 Engine Switch
F9 5 Engine Start Signal
F10 15 Pre-Cooler Fan
F11 25 Condenser Fan
F12 20 Evaporator Fan
F13 7.5 Compressor Clutch
F14 5 Heater ON
F15 2 Real Time Clock
F16 50 System Power
F17 2 Ground
F18 3 Voltage Sense
F19 1 Truck Ignition Input
F24 150 Main DPF Power (Option)
SSppeecciiffiiccaattiioonnss
