Table 11. Water connection dimensions — 150 to 330 ton units, extended length, without free-cooling or pump
package
Unit Size
(tons)
150, 165 180, 200 225, 250 275, 300, 330
Dim in mm in mm in mm in mm
X 20.4 520 19.6 498 21.8 554 20.6 523
Y 17.7 450 15.4 391 17.6 447 16.1 408
Z 49.3 1253 49.9 1268 49.9 1268 51.3 1303
AA 38.5 978 37.9 962 37.9 962 36.5 927
AB 19.3 490 17.6 448 19.8 504 18.2 463
AC 19.7 500 18.2 463 20.4 519 18.9 481
AD 229.3 5824 231.0 5867 231.0 5867 231.2 5872
AE 123.1 3127 122.1 3101 122.1 3101 122.1 3101
AF 227.9 5794 229.1 5819 229.1 5819 229.9 5839
Dimensions and Weights
