Table 12. Water connection dimensions — 150 to 330 ton units, with free-cooling (no pump package)
Unit Size
(tons)
165
180, 200 225, 250
275
300, 330
Dim in mm in mm in mm in mm in mm
Standard Length
X 20.4 520 19.6 498 21.8 554 20.6 523 20.6 523
Z 49.3 1253 49.9 1268 49.9 1268 51.3 1303 51.3 1303
AC 19.7 500 18.2 463 20.4 519 18.9 480 18.9 480
AD
(a)
270.9 6882 270.9 6881 270.9 6881 298.8 7588 298.8 7588
AE 70.3 1786 69.2 1758 69.2 1758 69.3 1760 69.3 1760
AF 176.2 4475 176.2 4475 176.2 4475 177.1 4498 177.1 4498
AG 270.9 6881 270.9 6881 270.9 6881 298.8 7588 298.8 7588
Extended Length
(b)
X 20.4 520 19.6 498 21.8 554 20.6 523 20.6 523
Z 49.3 1253 49.9 1268 49.9 1268 51.3 1303 51.3 1303
AC 19.7 500 18.2 463 20.4 519 18.9 480 18.9 480
AD
(a)
323.7 8222 323.7 8222 323.7 8222 351.6 8930 351.6 8930
AE 123.1 3127 122.0 3100 122.0 3100 122.0 3100 122.0 3100
AF 228.0 5791 229.1 5819 229.1 5819 229.1 5819 229.1 5819
AG 323.7 8222 323.7 8222 326.5 8293 351.6 8930 351.6 8930
Note: Free-cooling defined by model number digit 42: T = TDFC; J = DFC1; H = DFC2.
(a)
Only applicable on units with direct free-cooling cooling option (model number digit 42 = T, J, or H).
(b)
Extended Length is required for voltages 200V, 230V, 380V, 400V, 575V (model number digit 9 = A, B, C, D, F), and harmonic filtration model number digit 44 = L.
Table 13. Water connection inlet dimensions — 275, 300, 330 ton units with pump package option
Unit Option Standard Length Extended Length
(a)
Dim in mm in mm
AK 383.5 9741 436.3 11081
AL 2.9 73 2.9 73
AM 27.2 691 27.2 691
Note: Free-cooling defined by model number digit 42: T = TDFC; J = DFC1; H = DFC2.
(a)
Extended Length is required for voltages 200V, 230V, 380V, 400V, 575V (model number digit 9 = A, B, C, D, F), and harmonic filtration model number digit 44 = L.
Table 14. Water connection outlet dimensions — 275, 300, 330 ton units with pump package option
Unit Option
50HP 2-Pass
60HP or
75HP 2-Pass
50HP 3-Pass
60HP or
75HP 3-Pass
Dim in mm in mm in mm in mm
Standard Length
AH 191.6 4866 193.4 4913 54.5 1385 52.3 1327
AI 4.5 115 0.6 16 7 177 8 204
AJ 18.9 481 18.9 481 20.6 523 19.6 497
Extended Length
(a)
AH 244.4 6208 246.3 6255 107.3 2727 105.1 2669
AI 4.5 115 0.6 16 7 177 8 20
AJ 18.9 481 18.9 481 20.6 523 19.6 497
Note: Pump Package defined by model number digit 40 = 5 (50 HP), 6 (60 HP), 7 (75 HP). Pass options are defined by model number digits 19 and 20 (C2 or D2 are 2-
pass, C3 is 3-pass).
(a)
Extended Length is required for voltages 200V, 230V, 380V, 400V, 575V (model number digit 9 = A, B, C, D, F), and harmonic filtration model number digit 44 = L.
