Getting Started
To install an Symbio™ 800 AdaptiView display upgrade kit, the
technician must have good knowledge of the Symbio 800
control systems. Training in Symbio 800 controls is highly
recommended before beginning this upgrade.
Nameplate
A Symbio™ 800 AdaptiView display upgrade nameplate is
included in the kit to be installed near the original nameplate on
the control panel. Provide the model number and serial
number information from the nameplate when making
inquiries, ordering parts, or literature for the Symbio 800
AdaptiView display system.
Symbio 800 AdaptiView Display
Upgrade Kit Contents
Running the IPC Bus
All optional devices on the chiller must be connected to the IPC
communication bus. Verify all devices are connected, using
the correct cables, so no open plugs remain.
Figure 1. Symbio 800 AdaptiView nameplate example
SYMBIO 800 UPGRADE CONTROL FOR USE ON
LIQUID CHILLERS
MODEL NO: CDUB7A105AA00100000
SERIAL NO: L22C01079
ORDER NO: LARRYSP4
ORIGINAL SERIAL NO: L22A00000
LITERATURE:
CDUB-SVN02*-EN
CTV-SVU004*-EN
CVRF-SVP001*-EN
CTV-SVD005*-EN
CVHE-SVX005*-EN
BAS-SVU047*-EN
CTV-SVP004*-EN
www.trane.com/Patent
Table 1. Basic bill of material for Symbio™ 800 control upgrade kit
Description Qty. Part Number
(a)
Mnemonic Part Number
(a)
Symbio AdaptiView color display (if new display ordered) 1 X13760359001 MOD03183
Symbio 800 controller 1 X13651678020 MOD02979
Harness; Modbus distribution 1 453730970001 WIR10397
(a) All part number information in this table is subject to change at any time.
Figure 2. Modbus distribution harness
WARNING
Hazardous Voltage w/Capacitors!
Failure to disconnect power and discharge capacitors
before servicing could result in death or serious injury.
Disconnect all electric power, including remote
disconnects and discharge all motor start/run
capacitors before servicing. Follow proper lockout/
tagout procedures to ensure the power cannot be
inadvertently energized. For variable frequency drives
or other energy storing components provided by Trane
or others, refer to the appropriate manufacturer’s
literature for allowable waiting periods for discharge of
capacitors. Verify with a CAT III or IV voltmeter rated per
NFPA 70E that all capacitors have discharged.
