Trane Precedent TSK036 Series - Page 29

RT-SVX092A-EN
29
Figure 30. D.0 and D.1 cabinets – roof curb
117 3/16”
2977 MM
7 1/2”
191 MM
81”
2057 MM
1”
25 MM
1”
25 MM
116 7/8”
2969 MM
28 9/16”
725 MM
23 1/4”
591 MM
22 1/4”
565 MM
1”
25 MM
1 13/16”
46 MM
1 1/2” (38 MM) PERIMETER
CURB FLANGE
7 7/16”
189 MM
14 1/16”
357 MM
2”
51 MM
69 1/2”
1765 MM
Figure 31. D.0 and D.1 cabinets – swing diameter for hinged door(s) option
32"
809MM
30"
754MM
36"
907MM
Dimensions and Weights
