Table 3. Model weights, corner weights (lbs) and center of gravity dimensions (in.) (continued)
Tons Unit Model No.
Model Weights
(a)
Corner Weights
(b)
Center of Gravity (in.)
Shipping
Net A B C D
Length
Width
High Efficiency
3 THK036 667 589 184 165 111 147 31 19
4 THK048 875 777 293 231 112 142 39 17
5 THK060 895 797 293 239 119 146 40 18
6 THK072 986 892 319 267 139 167 41 18
7.5 THK090 1008 914 327 273 143 171 41 18
8.5 THK102 1029 935 335 280 146 175 41 18
10 THK120 1044 950 340 284 148 178 41 18
12.5 THK150 2040 1820 611 447 322 440 52 36
15 THK180 2040 1820 611 447 322 440 52 36
17.5 THK210 2070 1850 612 463 334 441 53 36
20 THK240 2140 1920 689 472 309 451 50 34
25 THK300 2190 1970 684 484 332 469 51 35
(a)
Weights are approximate. Weights do not include additional factory or field installed options/accessories. For option/accessory additional weights to be added to unit weight,
reference the following table.
(b)
Corner weights are given for information only.
Table 4. Model weights, corner weights (lbs) and center of gravity dimensions (in.) - gas/electric
Tons Unit Model No.
Model Weights
(a)
Corner Weights
(b)
Center of Gravity (in.)
Shipping
Net A B C D
Length
Width
Standard Efficiency
3 YSK036 728 651 201 165 125 160 31 19
4 YSK048 757 680 214 173 126 167 31 19
5 YSK060 779 702 222 175 129 176 30 19
6 YSK072 1031 937 328 279 152 177 41 18
7.5 YSK090 1060 966 338 287 158 183 41 18
8.5 YSK102 1092 998 346 294 295 187 41 19
10 YSK120 1111 1017 354 302 168 193 41 18
12.5 YSK150 1412 1218 464 343 175 236 43 21
15 YSK180 2220 2000 671 492 354 483 52 36
17.5 YSK210 2250 2030 672 509 366 484 53 36
20 YSK240 2320 2100 754 516 337 493 50 34
25 YSK300 2370 2150 746 529 363 512 51 35
High Efficiency
3 YHK036 728 651 201 165 125 160 31 19
4 YHK048 922 825 295 251 129 151 41 18
5 YHK060 951 853 304 259 133 156 41 18
6 YHK072 1031 937 328 279 152 177 41 18
7.5 YHK090 1060 966 338 287 158 183 41 18
8.5 YHK102 1092 998 346 294 295 187 41 19
10 YHK120 1111 1017 354 302 168 193 41 18
12.5 YHK150 2220 2000 671 492 354 483 52 36
15 YHK180 2220 2000 671 492 354 483 52 36
17.5 YHK210 2250 2030 672 509 366 484 53 36
