Installation Mechanical
32 RTHD-SVX02H-EN
Unit
Designator*
Dimension (mm (in))
A B C D E F
C2E1F1 3658 3353 1613 129 624 610
(144.02) (132.01) (63.50) (5.08) (24.57) (24.02)
C2D3E3 3048 2743 1517 225 618 610
(120.00) (107.99) (59.72) (8.86) (24.33) (24.02)
C2D4E4 3048 2743 1523 219 584 610
(120.00) (107.99) (59.96) (8.62) (22.99) (24.02)
C1E1F1 3658 3353 1613 129 624 610
(144.02) (132.01) (63.50) (5.08) (24.57) (24.02)
C1D3E3 3048 2743 1517 225 618 610
(120.00) (107.99) (59.72) (8.86) (24.33) (24.02)
C1D5E4 3048 2743 1523 219 584 610
(120.00) (107.99) (59.96) (8.62) (22.99) (24.02)
C1D6E5 3048 2743 1524 218 582 610
(120.00) (107.99) (60.00) (8.58) (22.91) (24.02)
C1C2D2 3658 3353 1459 93 523 610
(144.02) (132.01) (57.44) (3.66) (20.59) (24.02)
B2C2D2 3658 3353 1481 93 523 610
(144.02) (132.01) (58.31) (3.66) (20.59) (24.02)
B2B2B2 3048 2743 1476 98 535 610
(120.00) (107.99) (58.11) (3.86) (21.06) (24.02)
B1C1D1 3658 3353 1479 95 521 610
(144.02) (132.01) (58.23) (3.74) (20.51) (24.02)
B1B1B1 3048 2743 1447 97 534 610
(120.00) (107.99) (56.97) (3.82) (21.02) (24.02)
Total Heat Reclaim
B1C1H1 3658 3353 1479 95 620 610
(144.02) (132.01) (58.23) (3.74) (24.41) (24.02)
B2C2H2 3658 3353 1481 93 625 610
(144.02) (132.01) (58.31) (3.66) (24.61) (24.02)
C1E1J1 3658 3353 1613 129 748 610
(144.02) (132.01) (63.50) (5.08) (29.45) (24.02)
C2F2J3 3658 3353 1610 101 781 610
(144.02) (132.01) (63.39) (3.98) (30.75) (24.02)
D1F1J2 3658 3353 1612 99 779 610
(144.02) (132.01) (63.46) (3.90) (30.67) (24.02)
D2G2K1 3658 3353 1612 99 763 610
(144.02) (132.01) (63.46) (3.90) (30.04) (24.02)
D3G2K1 3658 3353 1612 99 763 610
(144.02) (132.01) (63.46) (3.90) (30.04) (24.02)
E3G2K1 3658 3353 1621 20 767 610
(144.02) (132.01) (63.82) (0.79) (30.20) (24.02)
Partial Heat Reclaim
B1C1L1 3658 3353 1479 95 555 610
(144.02) (132.01) (58.23) (3.74) (21.85) (24.02)
B2C2L2 3658 3353 1481 93 557 610
(144.02) (132.01) (58.31) (3.66) (21.93) (24.02)
C1E1M1 3658 3353 1613 129 668 610
(144.02) (132.01) (63.50) (5.08) (26.30) (24.02)
C2F2M3 3658 3353 1610 101 706 610
(144.02) (132.01) (63.39) (3.98) (27.80) (24.02)
D1F1M2 3658 3353 1612 99 705 610
(144.02) (132.01) (63.46) (3.90) (27.76) (24.02)
D2G2N1 3658 3353 1612 99 728 610
(144.02) (132.01) (63.46) (3.90) (28.66) (24.02)
D3G2N1 3658 3353 1612 99 728 610
(144.02) (132.01) (63.46) (3.90) (28.66) (24.02)
E3G2N1 3658 3353 1621 20 733 610
(144.02) (132.01) (63.82) (0.79) (28.86) (24.02)
* Designator corresponds to digits 6, 7, 14, 15, 21, 22 of model number
