Operating Principles Mechanical
76 RTHD-SVX02H-EN
Compressor Description
Figure 38. Compressor Description
Male Rotor
Female Rotor
Bearings
Load
So
lenoid
Piston
Housing
Bearing
Housing
Rotor
Housing
Suction
Motor
Housing
Slide Valve
Motor Stator
Discharge
Plenum
Unloader
Piston
Primary
Mounting
Holes
Oil Reclaim
Port
Bearing
Lubricant
Port
Rotor
Injection
Port
Discharge
Check Valve
Discharge
Check Valve
Unload
Solenoid
