Installation Mechanical
RTHD-SVX02H-EN 31
Lifting Procedure
D
CAUTION
Equipment Damage!
Never use a forklift to move the unit. The skid is not de-
signed to support the unit at any one point and using
a forklift to move the equipment may cause unit dam-
age. Always position the lifting beam so that cables do
not contact the unit. Failure to do so may result in unit
damage.
Note: If absolutely necessary, the chiller can be pushed
or pulled across a smooth surface if it is bolted to
wood shipping mounts.
D
WARNING
Shipping Mounts!
Do not use the threaded holes in the compressor to lift
or assist in lifting the unit. They are not intended for
that purpose and could create a dangerous situation.
Do not remove the wood mounts until the unit is in its
nal location. Removal of wood shipping mounts prior
to unit nal locating could result in death or serious
injury or equipment damage.
1. When the unit is at its final location, remove the
shipping bolts that secure the unit to the wood base
mounts.
2. Rig the unit properly and lift from above or jack
the unit (alternate moving method). Use the points
shown on the rigging diagram that ships with the
unit as shown in Figure 10. Remove the base mounts.
3. Install clevis connectors in lifting holes provided on
the unit. Attach lifting chains or cables to clevis con-
nectors as shown in Figure 10. Each cable alone must
be strong enough to lift the chiller.
Table 12. Rigging
Unit
Designator*
Dimension (mm (in))
A B C D E F
E3G2G1 3658 3353 1621 20 661 610
(144.02) (132.01) (63.82) (0.79) (26.02) (24.02)
E3F2F3 3658 3353 1612 29 615 610
(144.02) (132.01) (63.46) (1.14) (24.21) (24.02)
E3D2E2 3048 2743 1525 116 612 610
(120.00) (107.99) (60.04) (4.57) (24.09) (24.02)
D3G2G1 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D3F2F3 3658 3353 1610 101 617 610
(144.02) (132.01) (63.39) (3.98) (24.29) (24.02)
D3D2E2 3048 2743 1523 188 614 610
(120.00) (107.99) (59.96) (7.40) (24.17) (24.02)
D2G3G3 / D3G3G3 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D2G2G1 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D2F2F3 3658 3353 1610 101 617 610
(144.02) (132.01) (63.39) (3.98) (24.29) (24.02)
D2D2E2 3048 2743 1523 188 614 610
(120.00) (107.99) (59.96) (7.40) (24.17) (24.02)
D1G1G1 3658 3353 1614 97 661 610
(144.02) (132.01) (63.54) (3.82) (26.02) (24.02)
D1G2G2 3658 3353 1614 97 661 610
(144.02) (132.01) (63.54) (3.82) (26.02) (24.02)
D1F1F2 3658 3353 1612 99 622 610
(144.02) (132.01) (63.46) (3.90) (24.49) (24.02)
D1D1E1 3048 2743 1524 187 612 610
(120.00) (107.99) 60.00) (7.36) (24.09) (24.02)
C2F2F3 3658 3353 1610 101 617 610
(144.02) (132.01) 63.39) (3.98) (24.29) (24.02)
* Designator corresponds to digits 6, 7, 14, 15, 21, 22 of model number
