Installation Mechanical
50 RTHD-SVX02H-EN
Table 13. Evaporator and Condenser Data
Compress
or Frame
Code (Digit
6,7 of Model
No.)
Evap Shell
Code (Dig-
its 14, 15 of
Model No.)
Evap.
Shell
Diameter
(in)
Nominal Connector
size (NPS)*
Cond Shell
Code
(Digits 21,22 of
Model No.)
Cond. Shell
Diameter
(in)
Nom. Conn.
Size
(NPS)*
2-
Pass
3-
Pass
4-
Pass
Standard
Condenser
Heat
Reclaim
2-Pass 2-Pass
E3
D2 26.5 8 8 6 E2 22.0 8 -
F2 29.0 8 8 - E2 22.0 8 -
G2 33.5 - 10 8 G1 25.75 8 -
D3
D2 26.5 8 8 6 E2 22.0 8 -
F2 29.0 10 8 - F3 22.0 8 -
G2 33.5 - 10 8 G1 25.75 8 -
G3 33.5 - 10 8 G3 25.75 8 -
D2
G3 33.5 - 10 8 G3 25.75 8 -
D2 26.5 8 8 6 E2 22.0 8 -
F2 29.0 10 8 - F3 22.0 8 -
G2 33.5 - 10 8 G1 25.75 8 -
D1
D1 26.5 8 8 6 E1 22.0 8 -
F1 29.0 10 8 - F2 22.0 8 -
G1 33.5 - 10 8 G1 25.75 8 -
C2
D3 26.5 8 8 6 E3 22.0 8 -
D4 26.5 8 8 6 E4 22.0 8 -
E1 26.5 8 8 6 F1 22.0 8 -
F2 29.0 10 8 - F3 22.0 8 -
C1
D6 26.5 8 8 6 E5 22.0 8 -
D5 26.5 8 8 6 E4 22.0 8 -
D3 26.5 8 8 6 E3 22.0 8 -
E1 26.5 8 8 6 F1 22.0 8 -
C2 23.0 - 6 - D2 18.75 6 -
B2
C2 23.0 - 6 - D2 18.75 6 -
B2 23.0 - 6 - B2 18.75 6 -
B1
C1 23.0 - 6 - D1 18.75 6 -
B1 23.0 - 6 - B1 18.75 6 -
B1 C1 23.0 - 6 - H1 25.75 6 6
B2 C2 23.0 - 6 - H2 25.75 6 6
C1 E1 26.5 8 8 - J1 31.5 8 8
C2 F2 29.0 10 8 - J3 31.5 8 8
D1 F1 29.0 10 8 - J2 31.5 8 8
D2 G2 33.5 - 10 8 K1 31.5 8 8
D3 G2 33.5 - 10 8 K1 31.5 8 8
E3 G2 33.5 - 10 8 K1 31.5 8 8
B1 C1 23.0 - 6 - L1 22.0 6 3
B2 C2 23.0 - 6 - L2 22.0 6 3
C1 E1 26.5 8 8 - M1 26.5 8 4
C2 F2 29.0 10 8 - M3 26.5 8 4
D1 F1 29.0 10 8 - M2 26.5 8 4
D2 G2 33.5 - 10 8 N1 29.0 8 4
D3 G2 33.5 - 10 8 N1 29.0 8 4
E3 G2 33.5 - 10 8 N1 29.0 8 4
Metric Conversion is:
6 NPS = 150 mm nominal
8 NPS = 200 mm nominal
10 NPS = 250 mm nominal
