Figure 24. Condenser and Evaporator Water Connections - CEM
73.44 [1865 mm]
5.29 [134 mm]
14.50 [368 mm]
30.13 [765 mm]
10.20 [260 mm]
10.20 [260 mm]
14.88 [378 mm]
125.91 [3198mm]
IN
OUT
IN
IN
IN
OUT
OUT
43116.97 [ mm]
53120.91 [ mm]
75029.53 [ mm]
850
33.46
[ mm]
1646.46 [ mm]
2238.78 [ mm]
37514.76 [ mm]
53721.14 [ mm]
194976.73 [
mm]
41016.14 [ mm]
42316.65 [ mm]
57322.56 [ mm]
2108.27 [ mm]
2997118.00 [ mm]
0.01 [0 mm]
8.15 [207 mm]
71.42 [1814 mm]
Standard 3 -pass
Condenser
Evaporator
Evaporator
Oil Sump
