Installation Mechanical
30 RTHD-SVX02H-EN
Table 11. Center of Gravity(in(mm))
Unit Designator* X Y Z
E3G3G3 30.8 63.81 37.62
(782.32) (1621) (956)
E3G2G1 30.8 63.55 38.70
(782.32) (1614) (983)
E3F2F3 27.64 63.46 38.33
(702.06) (1612) (974)
E3D2E2 25.9 60.05 40.5
(658) (1525) (1029)
D3G3G3 30.85 63.48 37.44
(784) (1612) (951)
D3G2G1 30.58 68.56 37.79
(777) (1741) (960)
D3F2F3 27.7 63.4 38.14
(704) (1610) (969)
D3D2E2 25.97 59.95 40.31
(660) (1523) (1024)
D2G3G3 30.85 63.48 37.44
(784) (1612) (951)
D2G2G1 30.58 68.56 37.79
(777) (1741) (960)
D2F2F3 27.7 63.4 38.14
(704) (1610) (969)
D2D2E2 25.97 59.95 40.31
(660) (1523) (1024)
D1G1G1 30.58 68.56 37.79
(777) 1741) (960)
D1G2G2 30.77 63.55 37.72
(782) (1614) (958)
D1F1F2 27.92 63.47 38.7
(709) (1612) (9833)
D1D1E1 25.91 60 40.47
(658) (1524) (1028)
C2F2F3 27.92 63.47 38.7
(709) (1612) (9833)
C2E1F1 26.36 63.49 40.95
(670) (1613) (1040)
C2D3E3 26.13 59.74 40.08
(664) (1517) (1018)
C2D4E4 26.13 59.74 40.08
(664) (1517) (1018)
C1E1F1 26.36 63.49 40.95
(670) (1613) (1040)
C1D3E3 26.13 59.74 40.08
(664) (1517) (1018)
C1D5E4 26.13 59.74 40.08
(664) (1517) (1018)
C1D6E5 26.13 59.74 40.08
(664) (1517) (1018)
B2C2D2 22.4 58.29 33.51
(569) (1481) (851)
B2B2B2 22.88 58.11 35.43
(581) (1476) (900)
B1C1D1 22.32 58.23 33.65
(567) (1479) (855)
B1B1B1 22.84 58.13 35.59
(580) (1477) (904)
* Designator correponds to digits 6,7,14,15,21,22 of model number
Unit Designator* X Y Z
Total Heat Reclaim
B1C1H1 26 58 32
(666) (1481) (824)
B2C2H2 26 58 32
(671) (1483) (819)
C1E1J1 31 62 39
(794) (1582) (999)
C2F2J3 32 62 38
(824) (1583) (953)
D1F1J2 32 62 38
(822) (1584) (954)
D2G2K1 35 68 36
(883) (1732) (927)
D3G2K1 35 68 36
(883) (1732) (927)
E3G2K1 35 64 37
(887) (1621) (947)
Partial Heat Reclaim
B1C1L1 24 58 33
(601) (1480) (837)
B2C2L2 24 58 33
(603) (1482) (833)
C1E1M1 28 63 40
(714) (1592) (1027)
C2F2M3 29 63 38
(749) (1593) (974)
D1F1M2 29 63 38
(748) (1593) (974)
D2G2N1 33 68 37
(848) (1737) (939)
D3G2N1 33 68 37
(848) (1737) (939)
E3G2N1 34 64 38
(853) (1619) (961)
* Designator correponds to digits 6,7,14,15,21,22 of model number
