Trane RTHD series - Page 29

Installation Mechanical
RTHD-SVX02H-EN 29
Table 10. Unit Weight (lb(kg))
Location (points)
Unit Designator* A B C D
E3G2G1 5158 4304 4226 5300
(2340) (1952) (1917) (2404)
E3F2F3 4781 3582 3750 4851
(2169) (1625) (1701) (2200)
E3D2E2 3796 2834 3300 4789
(1722) (1285) (1497) (2172)
D3G3G3 5320 4451 4327 5140
(2413) (2019) (1963) (2331)
D3G2G1 5085 4255 4136 5171
(2307) (1930) (1876) (2346)
D3F2F3 4737 3563 3722 4797
(2149) (1616) (1688) (2176)
D3D2E2 3754 2818 3269 4720
(1703) (1278) (1483) (2141)
D2G3G3 5320 4451 4327 5140
(2413) (2019) (1963) (2331)
D2G2G1 5085 4255 4136 5171
(2307) (1930) (1876) (2346)
D2F2F3 4737 3563 3722 4797
(2149) (1616) (2176) (2176)
D2D2E2 3754 2818 3269 4720
(1703) (1278) (1483) (2141)
D1G1G1 4981 4148 4041 5076
(2259) (1882) (1833) (2302)
D1G2G2 5216 4344 4231 5316
(2366) (1970) (1919) (2411)
D1F1F2 4526 3452 3615 4594
(2053) (1566) (1640) (2084)
D1D1E1 3728 2758 3236 4694
(1691) (1251) (1468) (2129)
C2F2F3 4649 3496 4707 4707
2109 1586 2135 2135
C2E1F1 4205 3046 3196 4271
(1907) (1382) (1450) (1937)
C2D3E3 3612 2738 3148 4503
(1638) (1242) (1428) (2043)
C2D4E4 3374 2479 2876 4243
(1530) (1124) (1305) (1925)
C1E1F1 4205 3046 3196 4271
(1907) (1382) (1450) (1937)
C1D3E3 3612 2738 3148 4503
(1638) (1242) (1428) (2043)
C1D5E4 3375 2479 2876 4243
(1531) (1124) (1305) (1925)
C1D6E5 3330 2430 2825 4195
(1510) (1102) (1281) (1903)
C1C2D2 3946 2606 2055 3322
(1790) (1182) (932) (1507)
B2C2D2 3162 2297 1767 2726
(1510) (1042) (802) (1237)
B2B2B2 2522 1996 1926 2958
(1144) (905) (874) (1342)
B1C1D1 3136 2264 1739 2698
(1422) (1027) (789) (1224)
B1B1B1 2495 1969 1901 2928
(1132) (893) (862) (1328)
* Unit Designator (corresponds to digits 6,7,14,15,21,22 of unit
model number)
Location (points)
Unit Designator* A B C D
Total Heat Reclaim
B1C1H1 3430 2429 2255 3062
(1556) (1102) (1023) (1389)
B2C2H2 3463 2485 2315 3102
(1571) (1127) (1050) (1407)
C1E1J1 4819 3721 3858 4965
(2186) (1688) (1750) (2252)
C2F2J3 5165 4087 4246 5333
(2343) (1854) (1926) (2419)
D1F1J2 5161 4068 4228 5335
(2341) (1845) (1918) (2420)
D2G2K1 5432 4515 5258 6155
(2464) (2048) (2385) (2792)
D3G2K1 5432 4515 5258 6155
(2464) (2048) (2385) (2792)
E3G2K1 5798 4932 4934 5800
(2630) (2237) (2238) (2631)
Partial Heat Reclaim
B1C1L1 3183 2222 2017 2875
(1444) (1008) (915) (1304)
B2C2L2 3210 2255 2053 2910
(1456) (1023) (931) (1320)
C1E1M1 4385 3223 3389 4561
(1989) (1462) (1537) (2069)
C2F2M3 4700 3567 3796 4945
(2132) (1618) (1722) (2243)
D1F1M2 4709 3565 3794 4952
(2136) (1617) (1721) (2246)
D2G2N1 5240 4171 4870 5922
(2377) (1892) (2209) (2686)
D3G2N1 5240 4171 4870 5922
(2377) (1892) (2209) (2686)
E3G2N1 5604 4592 4548 5562
(2542) (2083) (2063) (2523)
* Unit Designator (corresponds to digits 6,7,14,15,21,22 of unit
model number)
