RLC-SVX09Q-EN
83
Table 32. Main processor diagnostics (continued)
Diagnostic
Name
Affects Target Severity
Persistence
Active Modes
[Inactive
Modes]
Criteria
Reset
Level
Manufacturer
Maintenance
Recommended -
xy
Cprsr Warning
Latch
Service
Messages
Enabled
Compressor service recommended as service interval
hours have elapsed.
Remote
Motor Winding
Temp Sensor -
xy
Cprsr
Warning
(tunable)
Latch All
Both of the motor winding temperature sensors are seen to
be out of their normal range. (Severity is adjustable via TU
Service Tool – default is warning)
Local
MP: Invalid
Configuration
Chiller Immediate Latch All
Reported if state chart misalignment in stopped or inactive
state occurred while a compressor was seen to be
operating and this condition lasted for at least 1 minute
(cprsr operation due to Service Pumpdown or with
Contactor Interrupt Failure diagnostic is excluded). The
presence of this software error message suggests an
internal software problem has been detected. The events
that led up to this failure, if known, should be recorded and
transmitted to Trane Controls Engineering.
Local
MP: Reset Has
OccurredC3:
I8H63C3:H7C3:
I9H63C3:H7C3:
I11H63C3:I58
Platform
Warning
NonLatch All
The main processor has successfully come out of a reset
and built its application. A reset may have been due to a
power up, installing new software or configuration. This
diagnostic is immediately and automatically cleared and
thus can only be seen in the Historic Diagnostic List in
Tracer TU.
Remote
No Differential
Refrigerant
Pressure - xy
Cprsr
Immediate Latch
Compressor
running on
Circuit
The system differential pressure was below 7.7 Psid (53
kPa) for 6 seconds after the 11 seconds ignore time relative
to cprsr/circuit start-up had expired. In a two compressor
circuit, the lower of the two suction pressure is used for
circuit DP.
Remote
Oil Flow
Protection Fault -
xy
Cprsr
Immediate Latch
Starter Contactor
Energized
[all Stop modes]
The Intermediate Oil Pressure Sensor for this cprsr is
reading a pressure either above its respective circuit’s
Condenser Pressure by 15 Psid or more, or below its
respective compressor Suction Pressure 10 Psid or more
for 30 seconds continuously.
Local
Oil Pressure
Sensor - xy
Cprsr
Immediate Latch All Bad Sensor or LLID Remote
Outdoor Air
Temperature
Sensor
Chiller
Warning
Latch All
Bad Sensor or LLID. If the outdoor temperature is used for
CHW reset, there shall be no CHW reset. Apply slew rates
per Chilled Water Reset spec. If installed for low ambient
lockout, there shall be no LA lockout imposed.
Remote
Pumpdown
Terminated –
Cktx
Circuit
Warning
NonLatch All
RTUD A/C only: Pumpdown was early terminated
(abnormal cause or expiration time) and Evaporator Liquid
Level is above -36mm whereas circuit is stopped.
Remote
Diagnostics
