Trane S Series - Chiller Log Sheet

RLC-SVX09Q-EN
95
Chiller Log Sheet
Chiller Log Sheet
Tab Measurement 15 minutes 30 minutes 1 hour
Main
Chiller Mode
Evaporator Entering/Leaving Water Temperature
Condenser Entering/Leaving Water Temperature
Active Chiller Water Setpoint (°F)
Average Line Current (%RLA)
Active Demand Limit Setpoint (%RLA)
Software Type
Software Version
Reports
EVAPORATOR
Entering Water Temperature (°F)
Leaving Water Temperature (°F)
Saturated Refrigerant Temperature (°F)
Refrigerant Pressure (psia)
Approach Temperature (°F)
Water Flow Switch Status
EXV Position (%)
EXV Position Steps
Refrigerant Liquid Level (inch)
CONDENSER
Entering Water Temperature (°F)
Leaving Water Temperature (°F)
Saturated Refrigerant Temperature (°F)
Refrigerant Pressure (psia)
Approach Temperature (°F)
Water Flow Switch Status
Head Pressure Control Command (%)
COMPRESSOR 1
Starts
Run Time
System Refrigerant Differential Pressure (psid)
Oil Pressure (psia)
Refrigerant Discharge Temperature (°F)
Discharge Superheat (°F)
% RLA L1 L2 L3 (%)
Log and Check Sheets
