Chiller Log Sheet
Tab Measurement 15 minutes 30 minutes 1 hour
Amps L1 L2 L3 (amps)
Volts AB BC CA
COMPRESSOR 2
Starts
Run Time
System Refrigerant Differential Pressure (psid)
Oil Pressure (psia)
Refrigerant Discharge Temperature (°F)
Discharge Superheat (°F)
% RLA L1 L2 L3 (%)
Amps L1 L2 L3 (amps)
Volts AB BC CA
Date:
Technician:
Owner:
Chiller Settings
Tab
Category Setting
Settings
CHILLER
Front Panel Water Setpoint (°F)
Front Panel Demand Limit Setpoint (°F)
Differential to Start (°F)
Differential to Stop (°F)
Setpoint Source
FEATURE SETTINGS
Chilled Water Reset
Return Reset Ratio
Return Start Reset
Return Maximum Reset
Outdoor Reset Ratio
Outdoor Start Reset
Outdoor Maximum Reset
MODE OVERRIDES
Evaporator Water Pump
Condenser Water Pump
Expansion Valve Control
Slide Valve Control
Service Pumpdown
