Table 33. Communication diagnostics (continued)
Diagnostic
Name
Affects Target Severity
Persistence
Active Modes
[Inactive
Modes]
Criteria
Reset
Level
Comm Loss:
Slide Valve Load
- xy
Cprsr
Normal Latch All
Continual loss of communication between the MP and the
Functional ID has occurred for a 30-second period.
Remote
Comm Loss:
Slide Valve
Unload - xy
Cprsr
Normal Latch All
Continual loss of communication between the MP and the
Functional ID has occurred for a 30-second period.
Remote
Comm Loss:
Starter Panel
High
Temperature
Limit –
Compressor 1A
Chiller Info Latch All
Continual loss of communication between the MP and the
Functional ID has occurred for a 30-second period.
Local
Comm Loss:
Starter xy
Cprsr
Immediate Latch All
Continual loss of communication between the MP and the
Functional ID has occurred for a 30-second period.
Local
Comm Loss:
Step Load - xy
Cprsr
Normal Latch All
Continual loss of communication between the MP and the
Functional ID has occurred for a 30-second period.
Remote
Comm Loss:
Suction
Refrigerant
Pressure - xy
Cprsr
Immediate Latch
All
[Ckt/Cprsr lock
out]
Continual loss of communication between the MP and the
Functional ID has occurred for a 30-second period.
Remote
Comm Loss:
Suction
Temperature
Circuit Normal Latch All
Continual loss of communication between the MP and the
Functional ID has occurred for a 30-second period.
Remote
