Trane S9V2B040U3PSC User Manual

18
S9V2-SVX001-1B-EN
Heating and Cooling Airflow Tables
Table 4. S9V2B040U3PSC Heating Airflow
S9V2B040U3PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 25,300
2nd Stage Capacity = 38,950
External Static Pressure
Heating
Airflow
Setting
Target
Airflow
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 468
CFM 468 452 437 421 406
Temp. Rise
49 51 54 56 58
Watts 27 58 90 121 152
Medium Low 598
CFM 552 600 647 694 741
Temp. Rise
43 39 36 32 28
Watts 41 76 112 147 183
Medium
(a)
634
CFM 583 635 687 739 791
Temp. Rise
39 36 33 30 27
Watts 48 83 118 153 189
High
864
CFM 753 786 818 850 883
Temp. Rise
30 29 28 27 26
Watts 87 129 171 214 256
Heating 2nd
Stage
Low 650
CFM 633 636 639 643 646
Temp. Rise
57 57 57 56 56
Watts 48 92 135 179 223
Medium Low 830
CFM 760 786 813 840 866
Temp. Rise
48 46 45 43 41
Watts 82 132 182 232 282
Medium
(a)
880
CFM 792 817 842 867 892
Temp. Rise
44 44 43 43 42
Watts 94 142 189 237 284
High
1200
CFM 1023 1044 1066 1088 1109
Temp. Rise
34 34 33 33 32
Watts 192 251 310 369 428
(a)
Factory Setting.
Table 5. S9V2B040D3PSC Heating Airflow
S9V2B040D3PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 25,300
2nd Stage Capacity = 38,850
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 468
CFM 464 453 442 431 420
Temp. Rise
51 52 53 54 55
Watts 26 55 84 113 142
Medium Low
(a)
634
CFM 616 607 599 591 583
Temp. Rise
38 38 39 40 40
Watts 40 78 115 152 190
Medium 684
CFM 635 643 650 658 666
Temp. Rise
37 37 36 36 35
Watts 47 106 165 224 283
High
900
CFM 824 843 861 880 898
Temp. Rise
28 28 27 26 26
Watts 82 130 178 226 274
Heating 2nd
Stage
Low 650
CFM 662 655 649 642 635
Temp. Rise
54 55 55 56 56
Watts 37 79 120 162 203
Medium Low
(a)
880
CFM 811 818 826 834 841
Temp. Rise
45 44 44 43 42
Watts 67 121 176 230 284
Medium 950
CFM 859 865 871 877 884
Temp. Rise
42 41 41 41 41
Watts 88 144 200 256 312
High
1250
CFM 1082 1092 1102 1111 1121
Temp. Rise
33 33 33 33 33
Watts 192 253 314 375 436
(a)
Factory Setting.
