Table 6. S9V2B040U3PSC/ S9V2B040D3PSC Cooling Airflow
S9V2B040U3PSC / S9V2B040D3PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
1.5 Ton
Cooling 450
CFM/Ton
CFM 675 675 675 675 675
Watts 47 81 121 166 215
Cooling 420
CFM/Ton
CFM 630 630 630 630 630
Watts 40 72 111 154 202
Cooling 400
CFM/Ton
CFM 600 600 600 600 600
Watts 36 67 105 147 193
Cooling 370
CFM/Ton
CFM 555 555 555 555 555
Watts 30 60 96 136 181
Cooling 350
CFM/Ton
CFM 525 525 525 525 525
Watts 27 56 90 130 174
Cooling 330
CFM/Ton
CFM 495 495 495 495 495
Watts 24 51 85 124 167
Cooling 310
CFM/Ton
CFM 465 465 465 465 465
Watts 21 48 80 118 161
Cooling 290
CFM/Ton
CFM 435 435 435 435 435
Watts 19 44 76 113 155
Cooling
2.0 Ton
Cooling 450
CFM/Ton
CFM 900 900 900 900 900
Watts 94 137 186 240 298
Cooling 420
CFM/Ton
CFM 840 840 840 840 840
Watts 79 120 166 218 273
Cooling 400
CFM/Ton
CFM 800 800 800 800 800
Watts 70 109 154 204 258
Cooling 370
CFM/Ton
CFM 740 740 740 740 740
Watts 58 95 138 185 236
Cooling 350
CFM/Ton
CFM 700 700 700 700 700
Watts 51 86 127 173 223
Cooling 330
CFM/Ton
CFM 660 660 660 660 660
Watts 44 78 118 162 211
Cooling 310
CFM/Ton
CFM 620 620 620 620 620
Watts 38 71 109 152 199
Cooling 290
CFM/Ton
CFM 580 580 580 580 580
Watts 33 64 101 142 188
Cooling
2.5 Ton
Cooling 450
CFM/Ton
CFM 1125 1125 1125 1125 1125
Watts 167 219 278 341 408
Cooling 420
CFM/Ton
CFM 1050 1050 1050 1050 1050
Watts 139 188 244 304 368
Cooling 400
CFM/Ton
CFM 1000 1000 1000 1000 1000
Watts 123 170 223 281 343
Cooling 370
CFM/Ton
CFM 925 925 925 925 925
Watts 100 145 195 250 308
Cooling 350
CFM/Ton
CFM 875 875 875 875 875
Watts 87 129 178 230 287
Cooling 330
CFM/Ton
CFM 825 825 825 825 825
Watts 121 160 205 254 308
Cooling 310
CFM/Ton
CFM 775 775 775 775 775
Watts 101 139 182 229 281
Cooling 290
CFM/Ton
CFM 725 725 725 725 725
Watts 88 123 164 210 260
Cooling
3.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 1350 1350 1350 1298 1198
Watts 272 334 402 440 450
Cooling 420
CFM/Ton
CFM 1260 1260 1260 1260 1198
Watts 226 284 348 417 450
Cooling 400
CFM/Ton
CFM 1200 1200 1200 1200 1198
Watts 198 254 315 381 450
Cooling 370
CFM/Ton
CFM 1110 1110 1110 1110 1110
Watts 161 213 271 333 399
Cooling 350
CFM/Ton
(a)
CFM 1050 1050 1050 1050 1050
Watts 139 188 244 304 368
Cooling 330
CFM/Ton
CFM 990 990 990 990 990
Watts 119 166 219 277 338
Cooling 310
CFM/Ton
CFM 930 930 930 930 930
Watts 102 146 197 252 311
Cooling 290
CFM/Ton
CFM 870 870 870 870 870
Watts 86 128 176 229 285
(a)
Factory Setting.
