Trane S9V2B040U3PSC User Manual

S9V2-SVX001-1B-EN
23
Table 10. S9V2B060U4PSC Cooling Airflow (continued)
S9V2B060U4PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
3.5 Ton
Cooling 450
CFM/Ton
CFM 1546 1570 1576 1564 1534
Watts 399 469 537 604 671
Cooling 420
CFM/Ton
CFM 1440 1462 1466 1453 1422
Watts 329 395 459 523 586
Cooling 400
CFM/Ton
CFM 1369 1391 1394 1380 1348
Watts 287 350 413 474 535
Cooling 370
CFM/Ton
CFM 1264 1284 1287 1271 1238
Watts 232 291 350 408 465
Cooling 350
CFM/Ton
CFM 1195 1214 1215 1199 1165
Watts 199 257 313 368 423
Cooling 330
CFM/Ton
CFM 1126 1144 1145 1127 1092
Watts 170 225 278 331 384
Cooling 310
CFM/Ton
CFM 1059 1075 1074 1056 1020
Watts 145 197 248 298 348
Cooling 290
CFM/Ton
CFM 992 1006 1004 985 948
Watts 122 171 219 267 315
Cooling
4.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 1779 1806 1814 1805 1778
Watts 585 661 737 812 886
Cooling 420
CFM/Ton
CFM 1654 1679 1686 1676 1647
Watts 480 552 624 695 765
Cooling 400
CFM/Ton
CFM 1572 1596 1602 1590 1561
Watts 418 488 557 625 693
Cooling 370
CFM/Ton
CFM 1450 1472 1477 1464 1433
Watts 335 401 466 530 594
Cooling 350
CFM/Ton
(a)
CFM 1369 1391 1394 1380 1348
Watts 287 350 413 474 535
Cooling 330
CFM/Ton
CFM 1289 1310 1312 1297 1264
Watts 244 305 364 423 481
Cooling 310
CFM/Ton
CFM 1210 1229 1231 1214 1180
Watts 206 264 320 376 431
Cooling 290
CFM/Ton
CFM 1131 1149 1150 1132 1097
Watts 172 227 281 334 386
(a)
Factory Setting.
Table 11. S9V2B080U4PSC Heating Airflow
S9V2B080U4PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 50,500
2nd Stage Capacity = 77,700
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM 914 882 849 816 783
Temp. Rise
51 53 55 57 59
Watts 90 131 172 213 255
Medium Low
(a)
907
CFM 940 912 885 858 831
Temp. Rise
50 51 53 54 56
Watts 104 141 178 215 253
Medium 958
CFM 983 932 881 830 779
Temp. Rise
47 50 53 55 58
Watts 118 151 184 218 251
High
1051
CFM 1029 1068 1107 1146 1185
Temp. Rise
45 44 42 40 39
Watts 155 195 235 275 314
Heating 2nd
Stage
Low 1200
CFM 1207 1206 1205 1204 1203
Temp. Rise
60 60 60 60 60
Watts 206 258 309 361 412
Medium Low
(a)
1260
CFM 1260 1261 1262 1263 1264
Temp. Rise
57 57 57 57 57
Watts 232 287 342 397 452
Medium 1330
CFM 1360 1347 1333 1320 1306
Temp. Rise
53 53 54 54 55
Watts 263 322 380 439 497
High
1460
CFM 1420 1439 1458 1477 1496
Temp. Rise
51 50 49 49 48
Watts 377 433 489 546 602
(a)
Factory Setting.
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
