RLC-SVX19G-GB
11
11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
General Data
Table 2b – General Data RTAF 090-185 Standard Efficiency - Standard and Low Noise (SN&LN) - R1234 ze
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 100 110 120 130 145 155 185
SE SN LN SE SN LN SE SN LN SE SN LN SE SN LN SE SN LN SE SN LN SE SN LN
Cooling Capacity (1) (kW) 325 357 387 419 450 502 544 602
Unit electrical data (2) (3) (4)
Maximum Power input in cooling (kW) 162 176 190 201 212 242 269 273
Unit rated amps (Max compressor+fan+control) (A) 272 295 318 339 360 409 450 458
Unit start up amps starting Amps of the larges compr+RLA
of 2nd compr+RLA of all fans+control)
(A) 370 412 435 467 488 559 600 608
Displacement Power Factor (DPF) 0.87 0.87 0.87 0.88 0.85 0.86 0.87 0.87
Max power cable cross section mm
²
1*240 1*240 1*240 1*240 1*240 2*300 2*300 2*300
Disconnect switch size (A) 400 400 500 500 500 630 630 630
Compressor
Quantity # 2 2 2 2 2 2 2 2
Type Screw Screw Screw Screw Screw Screw Screw Screw
Model (9) 45/45 55/45 55/55 65/55 65/65 78/65 78/78 78/78
Max Compr Power input (Circuit 1 / Circuit 2) kW 73/73 87/73 87/87 98/87 98/98 125/98 125/125 125/125
Max Amps Circuit1 / Circuit 2 (3) (5) (A) 119/119 142/119 142/142 163/142 163/163 204/163 204/204 204/204
Start up Amps Circuit1 / Circuit 2 (3)(5) (A) 217/217 259/217 259/259 291/259 291/291 354/291 354/354 354/354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit1 / Circuit 2 (W) 150/150
Evaporator
Quantity # 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 115B 115A 115A 165C 165B 200C 200C 200B
Evaporator Water Content volume (l) 51 58 58 64 74 89 89 99
Antifreeze Heater (W) 1.640 1.640 1.640 1.640 1.640 1.640 1.640 2.040
Two pass evaporator
Evap. Water Flow rate - Minimum (6) (l/s) 8.0 9.4 9.4 11.1 11.6 13.0 13.0 14.2
Evap. Water Flow rate - Maximum (l/s) 29.6 34.7 34.7 41.2 43.1 48.0 48.0 52.6
Nominal water connection size (Grooved coupling) (in) - (mm) 4" - 100 4" - 100 4" - 100 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150
Two pass evaporator with turbulator
Evap. Water Flow rate - Minimum (6) (l/s) 6.6 7.8 7.8 9.3 9.7 10.8 10.8 11.8
Evap. Water Flow rate - Maximum (l/s) 26.6 31.2 31.2 37.0 38.7 43.1 43.1 47.2
Nominal water connection size (Grooved coupling) (in) - (mm) 4" - 100 4" - 100 4" - 100 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150
Hydraulic Module Components
Standard head pressure pump option (twin pumps)
Available Head Pressure (1) (kPa) 129 126 111 107 136 121 160 151
Max. Motor Power (kW) 5.5 5.5 5.5 5.5 7.5 7.5 11.0 11.0
Max Amps (A) 11.0 11.0 11.0 11.0 14.4 14.4 20.8 20.8
High head pressure pump option (twin pumps)
Available Head Pressure (1) (kPa) 246 243 227 222 212 237 226 218
Max. Motor Power (kW) 11.0 11.0 11.0 11.0 11.0 15.0 15.0 15.0
Max Amps (A) 20.8 20.8 20.8 20.8 20.8 28.0 28.0 28.0
Expansion Tank Volume (l) 80 80 80 80 80 80 80 80
Max User water loop Volume for factory mounted
expansion tank (1)
(l) 6000 6000 6000 6000 6000 6000 6000 6000
Max. Water-side Operating Pressure without pump package (kPa) 1000 1000 1000 1000 1000 1000 1000 1000
Max. Water-side Operating Pressure with pump package (kPa) 450 450 450 450 450 450 450 450
Antifreeze Heater with pump package (W) 2400 2400 2400 2400 2400 2400 2400 2800
Condenser
Type MCHE
Quantity # 4/4 4/4 4/4 4/4 4/4 5/5 5/5 6/6
Face area per coil
(m²) 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan (nominal conditions)
Quantity # 4/4 4/4 4/4 4/4 4/4 5/5 5/5 6/6
Diameter (mm) 800 800 800 800 800 800 800 800
Standard / High ambient fan option
Fan / motor Type Propeller fan / Fixed speed - AC motor
Airow per Fan (m³/h) 20000 20000 20000 20000 20000 20000 20000 20000
Max Power input per Motor (kW) 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4
Max Amps per Motor (A) 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4
Motor RPM (rpm) 932 932 932 932 932 932 932 932
