Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Table 4a – General Data RTAF 090-245 Standard Efficiency - AC Extra Low Noise - R134a - R513A
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 140 145 150 155 170 175 185 190 200 205 245 (10)
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
SE AC
XLN
Cooling Capacity (1) (kW) 324 373 436 499 518 535 558 572 608 647 668 698 724 810
Unit electrical data (2) (3) (5)
Maximum Power input in
cooling
(kW) 133.1 154.3 182.5 211 213.6 233.08 236.0 255.48 258.9 281.26 284.1 304.16 307.0 307.0
Unit rated amps (Max compr
+Fan+Control)
(A) 221 259 309 359 364 394 399 429 438 473 479 512 518 517
Unit start up amps
(Starting Amps of the
largest compr+RLA of 2nd
compr+RLA of all fans+
control)
(A) 268 323 434 484 489 547 552 582 563 626 632 626 632 631
Displacement Power Factor
(DPF)
0.88 0.87 0.86 0.85 0.85 0.86 0.86 0.86 0.86 0.86 0.86 0.86 0.86 0.86
Max power cable cross
section
(mm
2
) 1x240 1x240 1x240 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300
Disconnect switch size (A) 400 400 500 630 630 630 630 630 630 800 800 800 800 800
Compressor
Quantity # 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Type Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw
Model (9) 45/45 50/50 70/50 70/70 70/70 85/70 85/70 85/85 100/70 100/85 100/85 100/100 100/100 100/100
Max Compr Power input
Circuit 1/Circuit 2
kW 60/60 71/71 99/71 99/72 99/99 121/98 121/99 121/121 144/99 144/121 144/121 144/144 144/144 144/144
Max Amps Circuit 1 / Circuit
2 (3) (5)
(A) 97/97 116/116 166/116 166/117 166/166 201/165 201/166 201/201 240/166 240/201 240/201 240/240 240/240 240/240
Start up Amps Circuit 1 /
Circuit 2 (3) (5)
(A) 144/144 180/180 291/180 291/181 291/291 354/290 354/291 354/354 354/291 354/354 354/354 354/354 354/354 354/354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit 1 /
Circuit 2
(W) 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150
Evaporator
Quantity # 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 115B 115A 165B 165B 165B 165A 165A 200B 200B 200B 200B 250C 250C 250B
Evaporator Water Content
volume
(l) 51 58 74 74 74 78 78 99 99 99 99 109 109 118
Antifreeze Heater (W) 1640 1640 1640 1640 1640 1640 1640 2040 2040 2040 2040 2040 2040 2040
Two pass evaporator
Evap. Water Flow rate -
Minimum
(l/s) 8.0 9.4 11.6 11.6 11.6 12.4 12.4 12.4 12.4 14.2 14.2 16.2 16.2 17.9
Evap. Water Flow rate -
Maximum (6)
(l/s) 29.6 34.7
43.1 43.1 43.1 46.0 46.0 46.0 46.0 52.6 52.6 60.3 60.3 66.5
Nominal water connection
size (Grooved coupling)
(in) -
(DN)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150
Two pass evaporator with turbulator
Evap. Water Flow rate -
Minimum (6)
(l/s) 6.6 7.8 9.7 9.7 9.7 10.3 10.3 10.3 10.3 11.8 11.8 13.5 13.5 14.9
Evap. Water Flow rate -
Maximum
(l/s) 26.6 31.2 38.7 38.7 38.7 41.3 41.3 41.3 41.3 47.2 47.2 54.1 54.1 59.7
Nominal water connection
size (Grooved coupling)
(in) -
(mm)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150 6" - 150 6" - 150
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Available Head Pressure
(1)
(kPa) 140 128 142 119 119 177 177 NA 173 154 154 143 143 143
Max Motor Power input (kW) 5.5 5.5 7.5 7.5 7.5 11.0 11.0 NA 11.0 11.0 11.0 11.0 11.0 11.0
Max Amps (A) 11 11 14 14 14 21 21 NA 21 21 21 21 21 21
High head pressure pump option (Twin Pump)
Available Head Pressure
(1)
(kPa) 252 239 223 NA 244 NA 235 NA 231 264 264 254 254 254
Max Motor Power input (kW) 11.0 11.0 11.0 NA 15.0 NA 15.0 NA 15.0 18.5 18.5 18.5 18.5 18.5
Max Amps (A) 21 21 21 NA 28 NA 28 NA 28 35 35 35 35 35
Expansion Tank Volume (l) 80 80 80 NA 80 NA 80 NA 80 80 80 80 80 80
Max User water loop
Volume for factory mounted
expansion tank (1)
(l) 6000 6000 6000 NA 6000 NA 6000 NA 6000 6000 6000 6000 6000 6000
Max. Water-side Operating
Pressure without pump
package
(kPa) 1000 1000 1000 NA 1000 NA 1000 NA 1000 1000 1000 1000 1000 1000
Max. Water-side Operating
Pressure with pump
package
(kPa) 450 450 450 NA 450 NA 450 NA 450 450 450 450 450 450
Antifreeze Heater with
pump package
(W) 2360 2360 2360 2360 2360 2360 2360 2760 2760 2760 2760 2760 2760 2760
General Data
