Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Table 6a – General Data RTAF 090-205 High Efficiency- AC Extra Low Noise - R134a - R513A
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 145 155 175 190 205
HE AC XLN HE AC XLN HE AC XLN HE AC XLN HE AC XLN HE AC XLN HE AC XLN HE AC XLN
Cooling Capacity (1) (kW) 330 381 450 529 572 627 683 744
Unit electrical data (2) (3) (5)
Maximum Power input in cooling (kW) 136 157 185 216 239 262 287 310
Unit rated amps (Max compr +Fan+Control) (A) 226 264 314 370 405 444 485 524
Unit start up amps (Starting Amps of the largest compr+RLA
of 2nd compr+RLA of all fans+ control)
(A) 273 328 439 495 558 569 638 638
Displacement Power Factor (DPF) 0.88 0.86 0.86 0.85 0.86 0.85 0.86 0.86
Max power cable cross section (mm
2
) 1x240 1x240 1x240 2x300 2x300 2x300 2x300 2x300
Disconnect switch size (A) 400 400 500 630 630 800 800 800
Compressor
Quantity # 2 2 2 2 2 2 2 2
Type Screw Screw Screw Screw Screw Screw Screw Screw
Model (9) 45/45 50/50 70/50 70/70 85/70 100/70 100/85 100/100
Max Compr Power input Circuit 1/Circuit 2 kW 60/60 71/71 99/71 99/99 121/99 144/99 144/121 144/144
Max Amps Circuit 1 / Circuit 2 (3) (5) (A) 97/97 116/116 166/116 166/166 201/166 240/166 240/201 240/240
Start up Amps Circuit 1 / Circuit 2 (3) (5) (A) 144/144 180/180 291/180 291/291 354/291 354/291 354/354 354/354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit 1 / Circuit 2 (W) 150/150 150/150 150/150 150/150 150/154 150/150 150/150 150/150
Evaporator
Quantity # 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 115B 115A 165B 165B 165A 200B 200B 250B
Evaporator Water Content volume (l) 51 58 74 74 78 99 99 118
Antifreeze Heater (W) 1640 1640 1640 1640 1640 2040 2040 2040
Two pass evaporator
Evap. Water Flow rate - Minimum (l/s) 8.0 9.4 11.6 11.6 12.4 14.2 14.2 17.9
Evap. Water Flow rate - Maximum (6) (l/s) 29.6 34.7 43.1 43.1 46.0 52.6 52.6 66.5
Nominal water connection size (Grooved coupling)
(in) -
(DN)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150
Two pass evaporator with turbulator
Evap. Water Flow rate - Minimum (6) (l/s) 6.6 7.8 9.7 9.7 10.3 11.8 11.8 14.9
Evap. Water Flow rate - Maximum (l/s) 26.6 31.2 38.7 38.7 41.3 47.2 47.2 59.7
Nominal water connection size (Grooved coupling)
(in) -
(mm)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Available Head Pressure (1) (kPa) 139 126 137 115 174 169 150 144
Max Motor Power input (kW) 5.5 5.5 7.5 7.5 11.0 11.0 11.0 11.0
Max Amps (A) 11 11 14 14 21 21 21 21
High head pressure pump option (Twin Pump)
Available Head Pressure (1) (kPa) 250 237 219 242 232 226 261 256
Max Motor Power input (kW) 11.0 11.0 11.0 15.0 15.0 15.0 18.5 18.5
Max Amps (A) 21 21 21 28 28 28 35 35
Expansion Tank Volume (l) 80 80 80 80 80 80 80 80
Max User water loop Volume for factory mounted expansion
tank (1)
(l) 6000 6000 6000 6000 6000 6000 6000 6000
Max. Water-side Operating Pressure without pump package (kPa) 1000 1000 1000 1000 1000 1000 1000 1000
Max. Water-side Operating Pressure with pump package (kPa) 450 450 450 450 450 450 450 450
Antifreeze Heater with pump package (W) 2360 2360 2360 2360 2360 2760 2760 2760
Condenser
Type
Full aluminum Micro channel heat exchanger
Quantity # 5/5 5/5 5/5 6/6 6/6 7/5 7/7 7/7
Face area per coil (m²) 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan
Quantity # 5/5 5/5 5/5 6/6 6/6 7/5 7/7 7/7
Diameter (mm) 800 800 800 800 800 800 800 800
Standard / High ambient fan option
Fan / motor Type Propeller fan / Fixed speed - AC motor
Airow per Fan (m
3
/h) 20000 20000 20000 20000 20000 20000 20000 20000
Max Power input per Motor (kW) 1.40 1.40 1.40 1.40 1.40 1.40 1.40 1.40
Max Amps per Motor (A) 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4
Motor RPM (rpm) 932 932 932 932 932 932 932 932
