Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
General Data
Table 8a – General Data RTAF 090-245 Extra Efficiency - Extra Low Noise - R134a - R513A
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 145 155 175 190 205 245
XE XLN XE XLN XE XLN XE XLN XE XLN XE XLN XE XLN XE XLN XE XLN
Cooling Capacity (1) (kW) 326 380 447 526 569 633 689 752
830
Unit electrical data (2) (3) (5)
Maximum Power input in cooling (kW) 141.1 162.3 190.5 222.6 245.0 267.9 294.2 317.1 317.1
Unit rated amps (Max compr +Fan+Control) (A) 227 265 315 371 406 445 486 525 525
Unit start up amps (Starting Amps of the
largest compr+RLA of 2nd compr+RLA of
all fans+ control)
(A) 274 329 440 496 559 570 639 639 639
Unit Power factor 0.90 0.89 0.88 0.87 0.87 0.87 0.88 0.87 0.87
Max power cable cross section (mm²) 240 240 240 2*300 2*300 2*300 2*300 2*300 2*300
Disconnect switch size (A) 400 400 500 630 630 630 800 800 800
Compressor
Quantity # 2 2 2 2 2 2 2 2 2
Type Screw Screw Screw Screw Screw Screw Screw Screw Screw
Model (9) 45/45 50/50 70/50 70/70 85/70 100/70 100/85 100/100 100/100
Max Compr Power input Circuit 1/Circuit 2 kW 60/60 71/71 99/71 99/99 121/99 144/99 144/121 144/144 144/144
Max Amps Circuit 1 / Circuit 2 (3) (5) (A) 97/97 116/116 166/116 166/166 201/166 240/166 240/201 240/240 240/240
Start up Amps Circuit 1 / Circuit 2 (3)
(5)
(A) 144/144 180/180 291/180 291/291 354/291 354/291 354/354 354/354 354/354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit 1 / Circuit 2 (W) 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150 150/150
Evaporator
Quantity # 1 1 1 1 1 1 1 1
1
Type Flooded shell and tube heat exchanger
Evaporator model 115B 115A 165B 165B 165A 200B 200B 250B 250B
Evaporator Water Content volume (l) 51 58 74 74 78 99 99 118 118
Antifreeze Heater (W) 1640 1640 1640 1640 1640 2040 2040 2040 2040
Two pass evaporator
Evap. Water Flow rate - Minimum (l/s) 8.0 9.4 11.6 11.6 12.4 14.2 14.2 17.9 17.9
Evap. Water Flow rate - Maximum (6) (l/s) 29.6 34.7 43.1 43.1 46.0 52.6 52.6 66.5 66.5
Nominal water connection size (Grooved
coupling)
(in) -
(DN)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150 6" - 150
Two pass evaporator with turbulator
Evap. Water Flow rate - Minimum (6) (l/s) 6.6 7.8 9.7 9.7 10.3 11.8 11.8 14.9 14.9
Evap. Water Flow rate - Maximum (l/s) 26.6 31.2 38.7 38.7 41.3 47.2 47.2 59.7 59.7
Nominal water connection size (Grooved
coupling)
(in) -
(mm)
4" - 100 4" - 100 5" - 125 5" - 125 5" - 125 6" - 150 6" - 150 6" - 150 6" - 150
Hydraulic Module Components
Standard head pressure pump option
Available Head Pressure (1) (kPa) 142 128 143 122 179 172 153 149 149
Max Motor Power input (kW) 5.5 5.5 7.5 7.5 11.0 11.0 11.0 11.0 11.0
Max Amps (A) 11.0 11.0 14.4 14.4 20.8 20.8 20.8 20.8 20.8
High head pressure pump option
Available Head Pressure (1) (kPa) 253 240 224 245 237 230 264 260 260
Max Motor Power input (kW) 11.0 11.0 11.0 15.0 15.0 15.0 18.5 18.5 18.5
Max Amps (A) 20.8 20.8 20.8 28.0 28.0 28.0 34.5 34.5 34.5
Expansion Tank Volume (l) 80 80 80 80 80 80 80 80 80
Max User water loop Volume for factory
mounted expansion tank (1)
(l) 6000 6000 6000 6000 6000
6000 6000 6000 6000
Max. Water-side Operating Pressure without
pump package
(kPa) 1000 1000 1000 1000 1000 1000 1000 1000 1000
Max. Water-side Operating Pressure with
pump package
(kPa) 450 450 450 450 450 450 450 450 450
Antifreeze Heater with pump package (W) 2360 2360 2360 2360 2360 2760 2760 2760 2760
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity # 5/5 5/5 5/5 6/6 6/6 7/5 7/7 7/7 7/7
Face area per coil (m²) 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan
Quantity # 5/5 5/5 5/5 6/6 6/6 7/5 7/7 7/7 7/7
Diameter (mm) 800 800 800 800 800 800 800 800 800
