Trane Sintesis RTAF HE series User Manual

RLC-SVX19G-GB
57
11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
General Data
Table 14a – General Data RTAF 250-450 standard efficiency Extra Low Noise - R134a - R513A
RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
250 280 310 350 355 380 410 450
SE XLN SE XLN SE XLN SE XLN SE XLN SE XLN SE XLN SE XLN
Cooling Capacity (1) (kW) 858 972 1074 1193 1186 1322 1447 1589
Unit electrical data (2) (3) (5)
Maximum Power input in cooling (kW) 371 420 466 522 525 572 621 700
Unit rated amps (Max compr +Fan+Control) (A) 614 694 772 862 870 946 1030 1163
Unit start up amps (Starting Amps of the largest
compr+RLA of 2nd compr+RLA of all fans+ control)
(A) 767 847 886 1015 952 1099 1144 1245
Displacement Power Factor (DPF) 0.87 0.88 0.87 0.88 0.87 0.87 0.87 0.87
Max power cable cross section (mm
2
) 4x185 4x185 4x185 4x185 4x185 4x185 4x185 6x185
Disconnect switch size (A) 1250 1250 1250 1250 1250 1250 1250 1600
Compressor
Quantity # 3 3 3 4 3 4 4 4
Type Screw Screw Screw Screw Screw Screw Screw Screw
Model (9) 85-85/70 85-100/85 100-100/100
85-85/
85-85
115-115/
115
85-100/
85-100
100-100/
100-100
115-115/
115-115
Max Compr Power input Circuit 1/Circuit 2 kW 121-121/99 121-144/121 144-144/144
121-121/
121-121
164-164/
164
121-144/
121-144
144-144/
144-144
164-164/
164-164
Max Amps Circuit 1 / Circuit 2 (3) (5) (A) 201-201/166 201-240/201 240-240/240
201-201/
201-201
273-273/
273
201-240/
201-240
240-240/
240-240
273-273/
273-273
Start up Amps Circuit 1 / Circuit 2 (3) (5) (A) 354-354/291 354-354/354 354-354/354
354-354/
354-354
354-354/
354
354-354/
354-354
354-354/
354-354
354-354/
354-354
Motor RPM (rpm) 3000 3000 3000 3000 3000 3000 3000 3000
Oil sump heater Circuit 1 / Circuit 2 (W) 300/150 300/150 300/150 300/300 300/300 300/300 300/300 300/300
Evaporator
Quantity # 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model 300D 300B 300A 500D 300A 500C 500B 500B
Evaporator Water Content volume (l) 97 108 120 146 120 159 170 170
Antifreeze Heater (W) 2240 2240 2240 2440 2440 2440 2440 2440
Two pass evaporator
Evap. Water Flow rate - Minimum (l/s) 17.7 20.1 22.8 25.0 22.8 27.8 30.3 30.3
Evap. Water Flow rate - Maximum (6) (l/s) 65.8 74.5 84.8 92.8 84.8 103.0 112.5 112.5
Nominal water connection size (Grooved coupling)
(in) -
(DN)
6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 200 8" - 200
Two pass evaporator with turbulator
Evap. Water Flow rate - Minimum (6) (l/s) 14.8 16.7 19.0 20.8 19.0 23.1 25.3 25.3
Evap. Water Flow rate - Maximum (l/s) 59.1 66.9 76.1 83.4 76.1 92.5 101.1 101.1
Nominal water connection size (Grooved coupling)
(in) -
(mm)
6" - 150 6" - 150 6" - 150 8" - 200 6" - 150 8" - 200 8" - 200 8" - 200
Hydraulic Module Components
Standard head pressure pump option (Twin pump)
Available Head Pressure (1) (kPa) 167 118 95 146 82 134 120 80
Max Motor Power input (kW) 15 15 15 22 15 22 22 22
Max Amps (A) 28 28 28 39.7 28 39.7 39.7 39.7
High head pressure pump option (Twin Pump)
Available Head Pressure (1) (kPa) 223 229 193 NA 175 NA NA NA
Max Motor Power input (kW) 19 22 22 NA 22 NA NA NA
Max Amps (A) 34.5 39.7 39.7 NA 39.7 NA NA NA
Expansion Tank Volume (l) 80 160 160 160 160 160 160 160
Max User water loop Volume for factory mounted
expansion tank (1)
(l)
4000 4000 4000 4000 4000 4000 4000 4000
Max. Water-side Operating Pressure without pump
package
(kPa) 1000 1000 1000 1000 1000 1000 1000 1000
Max. Water-side Operating Pressure with pump
package
(kPa) 450 450 450 450 450 450 450 450
Antifreeze Heater with pump package (W) 3300 3400 3400 3600 3400 3600 3600 3600
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity # 10/4 10/6 10/6 10/8 10/6 10/10 12/10 12/10
Face area per coil (m²) 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
Condenser Fan
Quantity # 10/4 10/6 10/6 10/8 10/6 10/10 12/10 12/10
Diameter (mm) 800 800 800 800 800 800 800 800
Standard / High ambient fan option
Fan / motor Type Propeller fan / Variable Speed - EC motor
Airow per Fan (m
3
/h) 20000 20000 20000 20000 20000 20000 20000 20000
Max Power input per Motor (kW) 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1
Max Amps per Motor (A) 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8
Motor RPM (rpm) 860 860 860 860 860 860 860 860
