Trane Tracer AdaptiView Installation Instructions

Installation
RCDA-SVN002C-EN 21
M1,M3 Curitiba, Pueblo, Taicang H = High Efficiency 460 113 150
M1,M3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 460 118 150
M1,M3 Curitiba, Pueblo, Taicang H = High Efficiency 380 136 150
M1,M3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 380 142 150
M1,M3 Curitiba, Pueblo, Taicang H = High Efficiency 230 225 275
M1,M3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 230 235 275
M1,M3 Curitiba, Pueblo, Taicang H = High Efficiency 200 259 275
M1,M3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 200 270 275
M1,M3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 220 0 0
M1,M3 Curitiba, Pueblo, Taicang H = High Efficiency 220 0 0
M1,M3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 400 118 150
M1,M3 Curitiba, Pueblo, Taicang H = High Efficiency 400 113 150
M1,M3 Charmes N = Standard, A = Extra Efficiency 400 110.5 150
M1,M3 Charmes H = High Efficiency 400 110.5 150
M1,M3 Charmes H = High Efficiency 380 138 150
M1,M3 Charmes N = Standard, A = Extra Efficiency 380 138 150
M1,M3 Charmes H = High Efficiency 460 114 150
M1,M3 Charmes N = Standard, A = Extra Efficiency 460 114 150
M2,M4 Curitiba, Pueblo, Taicang H = High Efficiency 575 106 150
M2,M4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 575 111 150
M2,M4 Curitiba, Pueblo, Taicang H = High Efficiency 400 133 150
M2,M4 Curitiba, Pueblo, Taicang H = High Efficiency 460 133 150
M2,M4 Curitiba, Pueblo, Taicang
N = Standard, A = Extra Efficiency 400 139 150
M2,M4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 460 139 150
M2,M4 Curitiba, Pueblo, Taicang H = High Efficiency 380 161 200
M2,M4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 380 168 200
M2,M4 Curitiba, Pueblo, Taicang H = High Efficiency 220 240 275
M2,M4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 220 251 275
M2,M4 Curitiba, Pueblo, Taicang H = High Efficiency 230 265 275
M2,M4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 230 278 400
M2,M4 Curitiba, Pueblo, Taicang H = High Efficiency 200 305 400
M2,M4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 200 320 400
M2,M4 Charmes N = Standard, A = Extra Efficiency 400 136 150
M2,M4 Charmes H = High Efficiency 400 136 150
M2,M4 Charmes H = High Efficiency 380 163 200
M2,M4 Charmes N = Standard, A = Extra Efficiency 380 163 200
M2,M4 Charmes H = High Efficiency 460 134 150
M2,M4 Charmes N = Standard, A = Extra Efficiency 460 134 150
N1,N3 Curitiba, Pueblo, Taicang H = High Efficiency 575 130 150
N1,N3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 575 134 150
N1,N3 Curitiba, Pueblo, Taicang H = High Efficiency 400 162 200
N1,N3 Curitiba, Pueblo, Taicang H = High Efficiency 460 162 200
N1,N3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 460 168 200
N1,N3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 400 168 200
N1,N3 Curitiba, Pueblo, Taicang H = High Efficiency 380
196 275
N1,N3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 380 203 275
N1,N3 Curitiba, Pueblo, Taicang H = High Efficiency 220 291 400
Table 15. Mapping table (continued)
Compressor
Frame Size
(a)
Manufacturing
Location
(b)
Unit Type
(Model Number Digit 12)
(c)
Unit
Voltage
(d)
Compressor
RLA
(e)
CT Meter
Scale
(f)
