Trane Tracer AdaptiView Installation Instructions

Installation
22 RCDA-SVN002C-EN
N1,N3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 220 306 400
N1,N3 Curitiba, Pueblo, Taicang H = High Efficiency 230 324 400
N1,N3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 230 336 400
N1,N3 Curitiba, Pueblo, Taicang H = High Efficiency 200 373 400
N1,N3 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 200 386 400
N1,N3 Charmes N = Standard, A = Extra Efficiency 400 162 200
N1,N3 Charmes H = High Efficiency 400 162 200
N1,N3 Charmes H = High Efficiency 380 202 275
N1,N3 Charmes N = Standard, A = Extra Efficiency 380 202 275
N1,N3 Charmes H = High Efficiency 460 166 200
N1,N3 Charmes N = Standard, A = Extra Efficiency 460 166 200
N2,N4 Curitiba, Pueblo, Taicang H = High Efficiency 575 155 200
N2,N4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 575 160 200
N2,N4 Curitiba, Pueblo, Taicang H = High Efficiency 400 194 275
N2,N4 Curitiba, Pueblo, Taicang H = High Efficiency 460 194 275
N2,N4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 400 200 275
N2,N4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 460 200 275
N2,N4 Curitiba, Pueblo, Taicang H = High Efficiency 380 235 275
N2,N4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 380 242 275
N2,N4 Curitiba, Pueblo, Taicang H = High Efficiency 220 344 400
N2,N4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 220 359 400
N2,N4 Curitiba, Pueblo, Taicang H = High Efficiency 230 388 400
N2,N4 Curitiba, Pueblo, Taicang
N = Standard, A = Extra Efficiency 230 399 400
N2,N4 Curitiba, Pueblo, Taicang H = High Efficiency 200 447 500
N2,N4 Curitiba, Pueblo, Taicang N = Standard, A = Extra Efficiency 200 459 500
N2,N4 Charmes N = Standard, A = Extra Efficiency 400 196.5 200
N2,N4 Charmes H = High Efficiency 400 196.5 200
N2,N4 Charmes H = High Efficiency 380 240 275
N2,N4 Charmes N = Standard, A = Extra Efficiency 380 240 275
N2,N4 Charmes H = High Efficiency 460 198 200
N2,N4 Charmes N = Standard, A = Extra Efficiency 460 198 200
(a) For compressor frame size, see compressor nameplate or ship history.
(b)Located in Design group in Tracer TU configuration.
(c) See unit nameplate for model number.
(d)Located in Tracer TU UC800 group or on compressor nameplate.
(e) Located in Tracer TU Starter group or on compressor nameplate.
(f) Located in Tracer TU Starter group.
Table 15. Mapping table (continued)
Compressor
Frame Size
(a)
Manufacturing
Location
(b)
Unit Type
(Model Number Digit 12)
(c)
Unit
Voltage
(d)
Compressor
RLA
(e)
CT Meter
Scale
(f)
