CNT-SVX09B-EN 5
Chapter 2
General wiring information
This chapter provides specifications and general information about wir-
ing the Tracer MP503 I/O module. The module requires wiring for:
Input/output terminals
AC power to the module
Communication-link wiring, if the module is to communicate with a
building automation system (BAS) or other LonTalk devices
Input/output terminal wiring
All input/output terminal wiring for the Tracer MP503 I/O module must
meet the following requirements:
All wiring must comply with the National Electrical Code and local
codes.
Use only 18 AWG twisted-pair wire with stranded, tinned-copper con-
ductors. (Shielded wire is recommended.)
Binary output wiring must not exceed 1000 ft (300 m).
Binary input and 4–20 mA input wiring must not exceed 1000 ft
(300 m).
Thermistor input and 0–10 Vdc input wiring must not exceed 300 ft
(100 m).
Do not run input/output wires in the same wire bundle with any ac-
power wires.
For detailed wiring information and diagrams, see Chapter 4, “Applica-
tions of the Tracer MP503.
