Chapter 6
Status indicators for
operation and
communication
This chapter describes the operation and communication status indica-
tors on the Tracer MP503 I/O module, including:
• A description of the location and function of the Service Pin button
and the light-emitting diodes (LEDs) located on the module
• A complete list of the diagnostics that can occur, their effect on mod-
ule outputs, and an explanation of how diagnostics are cleared and
the device restored to normal operation
