CNT-SVX09B-EN 1
Chapter 1
Overview and specifications
This guide provides installation and configuration information for the
Tracer MP503 input/output (I/O) module, as well as a description of its
operations. The overview includes a product description, specifications,
and descriptions of additional components needed in some Tracer MP503
applications.
Product description
The Tracer MP503 I/O module is a field-installed device used to monitor
inputs and control binary outputs. The module has four universal inputs
that can be configured as binary, thermistor, 0–20 mA, or 0–10 Vdc, as
well as four binary outputs.
Storage environment
If a Tracer MP503 I/O module is to be stored for a substantial amount of
time, store it in an indoor environment that meets the following
requirements:
• Temperature: –40° to 185°F (–40° to 85°C)
• Relative humidity: 5–95%, noncondensing
Operating environment
Operate a Tracer MP503 I/O module in an environment that meets the
following requirements:
• Temperature: –40°F to 158°F (–40°C to 70°C)
• Relative humidity: 5–95%, non-condensing
Dimensions
Plastic-cover model dimensions
For complete dimensional drawing, see .
• Height: 5.375 in. (137 mm)
• Width: 6.875 in. (175 mm)
• Depth: 2 in. (51 mm)
