Chapter 5 Network variable bindings
16 CNT-SVX09B-EN
Tracer MP503 bindings
The principal purposes of a Tracer MP503 I/O module are to gather data
(sensor readings) for use by a BAS or peer device and to allow a BAS or
peer device to control Tracer MP503 binary outputs. Therefore, the use of
bindings is very important in Tracer MP503 applications.
The examples in this chapter illustrate some common applications in
which bindings are used with the Tracer MP503.
Receiving data
A network variable input (nvi) receives data from other devices on the
LonTalk network. Network variable inputs (including their SNVTs) that
are commonly used in Tracer MP503 bindings are shown in Table 1.
Table 1. Tracer MP503 network variable inputs
Variable name Data type Description
nviBOP1Request SNVT_switch Binary output 1
request
The requested state of binary output 1.
Bind to this nvi to control the binary output from
another device on the network.
nviBOP2Request SNVT_switch Binary output 2
request
The requested state of binary output 2.
Bind to this nvi to control the binary output from
another device on the network.
nviBOP3Request SNVT_switch Binary output 3
request
The requested state of binary output 3.
Bind to this nvi to control the binary output from
another device on the network.
nviBOP4Request SNVT_switch Binary output 4
request
The requested state of binary output 4.
Bind to this nvi to control the binary output from
another device on the network.
