Tracer MP503 bindings
CNT-SVX09B-EN 17
Sending data
A network variable output (nvo) sends data to other devices on the Lon-
Talk network. The network variable outputs (including their SNVTs) that
are commonly used in Tracer MP503 bindings are shown in Table 2.
Table 2. Tracer MP503 network variable outputs
Variable name Data type Description
nvoTemperature1 SNVT_temp_p Universal input 1 sta-
tus output
Indicates the value of universal input 1 if it is
configured as thermistor.
If universal input 1 is not configured as ther-
mistor, this output is invalid.
nvoTemperature2 SNVT_temp_p Universal input 2 sta-
tus output
Indicates the value of universal input 2 if it is
configured as thermistor.
If universal input 2 is not configured as ther-
mistor, this output is invalid.
nvoTemperature3 SNVT_temp_p Universal input 3 sta-
tus output
Indicates the value of universal input 3 if it is
configured as thermistor.
If universal input 3 is not configured as ther-
mistor, this output is invalid.
nvoTemperature4 SNVT_temp_p Universal input 4 sta-
tus output
Indicates the value of universal input 4 if it is
configured as thermistor.
If universal input 4 is not configured as ther-
mistor, this output is invalid.
nvoBIP1Status SNVT_switch Universal input 1 sta-
tus output
Indicates the value of universal input 1 if it is
configured as binary.
If universal input 1 is not configured as
binary, this output is invalid.
nvoBIP2Status SNVT_switch Universal input 2 sta-
tus output
Indicates the value of universal input 2 if it is
configured as binary.
If universal input 2 is not configured as
binary, this output is invalid.
nvoBIP3Status SNVT_switch Universal input 3 sta-
tus output
Indicates the value of universal input 3 if it is
configured as binary.
If universal input 3 is not configured as
binary, this output is invalid.
nvoBIP4Status SNVT_switch Universal input 4 sta-
tus output
Indicates the value of universal input 4 if it is
configured as binary.
If universal input 4 is not configured as
binary, this output is invalid.
nvoCurrent1 SNVT_amp_mil Universal input 1 sta-
tus output
Indicates the value of universal input 1 if it is
configured as 0–20 mA.
If universal input 1 is not configured as 0–20
mA, this output is -3276.8.
nvoCurrent2 SNVT_amp_mil Universal input 2 sta-
tus output
Indicates the value of universal input 2 if it is
configured as 0–20 mA.
If universal input 2 is not configured as 0–20
mA, this output is -3276.8.
