Trane UniTrane Installation, Operation And Maintenance Instructions

UNT-SVX07B-EN 61
Installation—Electrical
04 0.05 1/20
0.06 1/16
0.10 1/10
0.13 1/8
06 0.07 1/15
0.12 1/8
0.16 1/6
0.24 1/4
08 0.12 1/8
0.13 1/8
0.24 1/4
10 0.05 0.07 1/20 1/15
0.06 0.12 1/16 1/8
0.10 0.16 1/10 1/6
0.13 0.24 1/8 1/4
12 0.05 0.12 1/20 1/8
0.06 0.13 1/16 1/8
0.10 0.24 1/10 1/4
0.13 0.24 1/8 1/4
Low Vertical - 03, 04, 06 0.03 1/30
Table 6. Free-discharge motors on units with two-row, electric, or steam coils
Unit
Size
115 Volt 208–230 Volt 277–480 Volt rpm
FLAhp (kW)FLAhp (kW)FLAhp (kW) H M L
02 0.60 0.03 (0.02) 0.3 0.03 (0.02) 0.2 0.03 (0.02) 980 840 655
03 0.70 0.04 (0.02) 0.4 0.04 (0.02) 0.3 0.04 (0.02) 980 780 580
04 0.90 0.05 (0.04) 0.5 0.05 (0.04) 0.4 0.05 (0.04) 1050 780 580
06 1.20 0.07 (0.05) 0.6 0.07 (0.05) 0.5 0.07 (0.05) 1030 780 580
08 1.40 0.12 (0.09) 0.9 0.12 (0.09) 0.6 0.12 (0.09) 1080 800 600
10 0.90 0.05 (0.04) 0.5 0.05 (0.04) 0.4 0.05 (0.04) 1050 780 580
1.20 0.07 (0.05) 0.6 0.07 (0.05) 0.5 0.07 (0.05) 1030 780 580
12 0.90 0.05 (0.04) 0.5 0.05 (0.04) 0.4 0.05 (0.04) 1050 780 580
1.40 0.12 (0.09) 0.9 0.12 (0.09) 0.6 0.12 (0.09) 108 800 600
Note: Actual rpm will vary with application and configuration. Size 10 and 12 units have two motors.
Table 7. High-static motors on units with two-row, electric, or steam coils
Unit
Size
115 Volt 208–230 Volt 277–480 Volt rpm
FLAhp (kW)FLAhp (kW)FLAhp (kW) H M L
2 1.10 0.07 (0.05) 0.6 0.07 (0.05) 0.5 0.07 (0.05) 1480 1110 865
3 1.40 0.08 (0.06) 0.7 0.08 (0.06) 0.6 0.08 (0.06) 1400 1175 860
4 1.60 0.10 (0.07) 0.8 0.10 (0.07) 0.7 0.10 (0.07) 1475 1315 1070
6 2.60 0.16 (0.12) 1.2 0.16 (0.12) 1 0.16 (0.12) 1400 1070 855
8 3.40 0.24 (0.18) 1.4 0.24 (0.18) 1.1 0.24 (0.18) 1475 1285 975
10 1.60 0.10 (0.07) 0.8 0.10 (0.07) 0.7 0.10 (0.07) 1475 1315 1070
2.60 0.16 (0.12) 1.2 0.16 (0.12) 1 0.16 (0.12) 1400 1070 855
12 1.60 0.10 (0.07) 0.5 0.10 (0.07) 0.7 0.10 (0.12) 1475 1315 1240
3.40 0.24 (0.18) 0.9 0.24 (0.18) 1.1 0.24 (0.18) 1475 1285 975
Note: Actual rpm will vary with application and configuration. Size 10 and 12 units have two motors.
Table 5. Decimal to fractional HP (kW) conversion (continued)
FC Decimal Fraction
Note: Fractional HP (kW) values are approximate values and not necessarily actual HP (kW).
