Trane UniTrane Installation, Operation And Maintenance Instructions

62 UNT-SVX07B-EN
Installation—Electrical
Table 8. Free-discharge motors on units with three- and four-row coils
Unit
Size
115 Volt 208–230 Volt 277–480 Volt rpm
FLAhp (kW)FLAhp (kW)FLAhp (kW) H M L
2 0.60 0.03 (0.02) 0.3 0.03 (0.02) 0.2 0.03 (0.02) 980 840 655
3 0.80 0.05 (0.04) 0.5 0.05 (0.04) 0.4 0.05 (0.04) 1080 800 600
4 1.00 0.06 (0.04) 0.6 0.06 (0.04) 0.5 0.06 (0.04) 1080 800 600
6 1.40 0.12 (0.09) 0.9 0.12 (0.09) 0.6 0.12 (0.09) 1080 800 600
8 1.70 0.13 (0.10) 1.0 0.13 (0.10) 0.8 0.13 (0.10) 1080 800 600
10 1.00 0.06 (0.04) 0.6 0.06 (0.04) 0.5 0.06 (0.04) 1080 800 600
1.40 0.12 (0.09) 0.9 0.12 (0.09) 0.6 0.12 (0.09) 1080 800 600
12 1.00 0.06 (0.04) 0.6 0.06 (0.04) 0.5 0.06 (0.04) 1080 800 600
1.70 0.13 (0.10) 1.0 0.13 (0.10) 0.8 0.13 (0.10) 1080 800 600
Note: Actual rpm will vary with application and configuration. Size 10 and 12 units have two motors.
Table 9. High-static motors on units with three- and four-row coils
Unit
Size
115 Volt 208–230 Volt 277–480 Volt rpm
FLAhp (kW)FLAhp (kW)FLAhp (kW) H M L
2 1.10 0.07 (0.05) 0.6 0.07 (0.05) 0.5 0.07 (0.05) 1480 1110 865
3 1.30 0.08 (0.06) 0.7 0.08 (0.06) 0.5 0.08 (0.06) 1500 1355 1110
4 2.10 0.13 (0.10) 0.9 0.13 (0.10) 0.7 0.13 (0.10) 1580 1375 1240
6 3.40 0.24 (0.18) 1.4 0.24 (0.18) 1.1 0.24 (0.18) 1475 1285 975
8 3.40 0.24 (0.18) 1.4 0.24 (0.18) 1.1 0.24 (0.18) 1475 1285 975
10 2.10 0.13 (0.10) 0.9 0.13 (0.10) 0.7 0.13 (0.10) 1580 1375 1240
3.40 0.24 (0.18) 1.4 0.24 (0.18) 1.1 0.24 (0.18) 1475 1285 975
12 2.10 0.13 (0.10) 0.9 0.13 (0.10) 0.7 0.13 (0.10 ) 1580 1375 1240
3.40 0.24 (0.18) 1.4 0.24 (0.18) 1.1 0.24 (0.18) 1475 1285 975
Note: Actual rpm will vary with application and configuration. Size 10 and 12 units have two motors.
Table 10. Fan-coil electric heat kW
Unit SizeUnit VoltagekWkWkWkWkWkWkWkWkWkWkW
02 115 1.0 1.5 2.0
230 1.0 1.5 2.0
277 1.0 1.5 2.0
208 0.8 1.1 1.5 1.9
03 115 1.0 1.5 2.0 2.5
230 1.0 1.5 2.0 2.5
277 1.0 1.5 2.0 2.5
208 0.8 1.1 1.5 1.9 2.3
04 115 2.0 2.5 3.0
230 2.0 2.5 3.0
277 2.0 2.5 3.0
208 1.5 1.9 2.3 3.0
