UNT-SVX07B-EN 73
Controls Interface
3. Configure the sensor options in the order shown in the table.
• P
ress or to scroll to the next selection (as illustrated).
• Press or to move to the next menu (as illustrated).
4. Review the display to ensure that you have selected the correct configuration.
5. To return the display to oper
ating mode, press the configuration button (see Step 1, p. 71).
Note: The sensor will revert to operating mode if no buttons are pressed for 10 minutes.
Setting Configuration Options
Temperature
• Choose Fahrenheit or Celsius
• Choose the degree resolution
(whole degrees, half degrees, or
tenths of degrees).
Setpoint
System
Fan
Note: Not all fan options are available
for all systems.
Occupancy (timed override)
. .
.
.
.
.
dual setpoint
no
setpoint
single
setpoint
no system
options enabled
auto/off/low
med/high
auto/off/
low/high
auto/off
off/high (on)
off/low/high off/low/
med/high
no fan options
enabled
