74 UNT-SVX07B-EN
Controls Interface
Optional Features
Displaying Setpoint or Temperature. You can configure the sensor to display either the
temperature (default) or setpoint. To select either option:
1. Verify that the sensor is in operating mode and at the home screen.
2. Press the up and down arrows for 3 seconds. The arrow indicates setpoint display, as shown
in the figure.
Locking or Unlocking Settings. You can lock or unlock the setpoint, system, or fan setting to
prevent changes.
To lock or unlock a setting:
1. Verify that the sensor is in operating mode and at the home screen.
2. Choose a setting to lock or unlock:
• S
elect the setpoint by pressing the up or down arrow.
• From the system menu press the down arrow to select the fan menu. Use the left or right
arrow to choose the setting.
3. Press the left and right arrows for 4 seconds.
Arrow
indicates
setpoint is
shown on
display
