51
Technical Specifications
Hardware
Standards Wired: IEEE 802.3u
Wireless: IEEE 802.11b, IEEE 802.11g, Based on IEEE
802.11n technology
LED Indicator Power, LAN, WLAN
Antenna 8dBi directional antenna
EXT (external antenna
connector)
N-Type Female connector (up to 15dBi)
PoE 12V 1 x 10/100Mbps RJ-45 PoE port, Passive only
(non-802.3af compliant)
Dimension (L x W x H) 228 x 64 x 61 mm (9.0 x 2.5 x 2.4 in)
Weight 500g (17.6 oz)
Power Consumption 12 Watts (max.)
Management Web browser (HTTP/HTTPS), SNMP (v2c and 3),
Telnet, SSH
Waterproof IP55 compliant
Temperature
Operating: -20° ~ 70°C (-4°F ~ 158°F)
Storage: -30° ~ 80°C (-22°F ~ 176°F)
Humidity Max. 95% (non-condensing)
Power Passive PoE power injector DC Output: 12VDC, 1A
Input: 100 –240V ~50/60Hz 1A
Certifications CE, FCC
Wireless
Frequency FCC: 2.412 ~ 2.452
ETSI: 2.412 ~ 2.472
Modes Access Point, CPE, Wireless Client AP, AP + Repeater
Virtual Access Points 16
Associated Clients (max) 32 (AP Mode), 32 (Repeater Mode)
*Coverage 10km line-of-sight
Modulation Technique OFDM, BPSK, QPSK, CCK, DQPSK, DBPSK
Data Rate (auto-fallback) 802.11b: up to 11Mbps
802.11g: up to 54Mbps
802.11n: up to 135Mbps
Security 64/128/152-bit WEP, WPA /WPA2-PSK, WPA/WPA2-
RADIUS for AP/CPE mode, WEP/WPA2-PSK for WDS
mode
MAC filter (32 entries)
Output Power 802.11b: 26dBm (typical)
802.11g: 24dBm (typical)
802.11n: 21dBm (typical)
Receiving Sensitivity 802.11b: -88dBm (typical) @ 11Mpbs
802.11g: -73dBm (typical) @ 54Mbps
802.11n: -67dBm (typical) @ 150Mbps
Channels FCC: 1~11
ETSI: 1~13
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual
data throughput and coverage will vary depending on interference, network traffic, building
materials and other conditions.
