Dryspell plus model 300:
Fill the desiccant bag assembly firstly with 3 bags of Activated Alumina AD1398 followed by a bag of molecular sieves
AD1424 as shown in the figure 34.
Dryspell plus model 375:
Fill the desiccant bag assembly firstly with 3 bags of Activated Alumina AD1398 followed by a bag of mixed Activated
alumina and Molecular Sieves AD1425, lastly with a bag of molecular sieves AD1424 as shown in the figure 35.
l Replace the top compactor plate with new one
l Fix the top block assembly and tighten the cap screws
l Connect the solenoid coil, inlet valve and pilot air connections
l Fasten the towers in the bottom by tightening the screws.
For changing the top shuttle in dryspell plus models 300 & 375 refer section 8.5.5.2
