Manual x/e-touchPANEL 02 | 01-2021 | 2.9 | en
Interfaces
c
105 / 118
1.
2.
3.
4.
7.5.3. Uploading a screen saver
Example screensaver:
Correct spelling Wrong spelling
screensaver.png screensaver.PNG
A connection via an Ethernet interface is established.
Click the link "more..." in the browser.
-> The File Up/Download page is displayed.
Click on the "Select file" button.
-> A box is displayed with a request to search for and open the respective file.
Search for the folder on the hard drive of the laptops / PC in which you have stored the desired file.
Select the file screensaver.png and click on the "Open file" button.
I NOTICE
The xetouch software is case sensitive. Pay attention to correct spelling.
