6.1. Overview
6.1.1. Design and functions
In the Basic, Colour and Plug Application the x/e-touchPANEL is an operating device and controller for DALI lighting
systems. The xetouch software that is controlled using a colour touchscreen is integrated into the
›x/e-touchPANEL‹. It is possible to use it in combination with ›comfortDIM series‹ controllers.
The ›xetouch‹ software provides the following functions:
Property x/e-touchPANEL
Number of DALI lines 2
Connection Maximum 128 DALI operating devices
Bus supply External
Interfaces USB, Ethernet
Frame light yes
Applications_
Basic for white light applications_
Colour for RGBW applications_
Plug for simple RGBW applications with preconfigured operating devices where the addressing is
already set using coded connectors
_
Configuration of_
16 scenes_
99 light sources_
7 time-controlled schedules_
1 calendar-controlled schedule list_
DT 8 (Tunable White)_
Real-time clock/calendar_
Configuration of the buttons for manual call-up_
Design of the buttons for manual call-up_
Manual switching and dimming_
Frame light and adjustable display light_
Communication via interfaces:_
USB_
Ethernet (TCP/IP)_
