4.1. Overview of the basic settings
The following table gives an overview of the basic settings of the x/e-touchPANEL. These are located in the
"Configuration" menu as tabs at the top of the page.
Tab Entry Function
Display Language Set the language.
Design Set the touchscreen design (Only in the Basic, Colour and Plug Application)
Clean Briefly lock the touchscreen for cleaning.
Frame light Define the function of the frame light
Beep on touch Activate or deactivate the sound when touching the display
Locking the
configuration
Lock or release the user interface in the Home menu
Screen saver Activate or deactivate the screen saver.
Locking the
display
Locking of releasing the touchscreen (password protected).
System Program version Displays the ›x-touch‹ software version
Device name Enter the name for the x/e-touchPANEL (For identification when several devices are
used).
Reset to factory
defaults
Reset the settings to the factory defaults, e.g. Layout,
Net recovery
action
Control the behaviour after the power supply is interrupted
Application Select the Application.
DALI Routing Allows to send commands from other controls (e.g. DALI XC, TOUCHPANEL 02)
from DALI line A to line B and vice versa.
This Function can be activated or deactivated.
DAP commands will be forwarded on address, group and Broadcast level.
Scene commands will only be forwarded on Broadcast level.
DALI Numbering Numbering from A1...A64 or A0...A63
TCP /
IP
MAC Displays the MAC address of the x/e-touchPANEL
