6.3. Basic Application
This chapter contains the following topics:
6.3.1. Addressing and grouping
Each operating device in the system must be individually addressed and assigned to a group so that the
x/e-touchPANEL can communicate with the operating devices. In Basic Application Addressing is performed
automatically; grouping has to be done manually.
With the following operating devices, the address number is supplemented by the specific abbreviation. The
identification of the components is only displayed if this is supported by the devices.
Device Type Abbreviation Type Example (Tridonic)
DT 0 Fluorescent lamps PCA
DT 1 EM Self-contained emergency lighting EM - PRO
DT 2 HID Discharge lamps (excluding fluorescent lamps) PCI Outdoor
DT 3 LV Low voltage halogen lamps TE o4a
DT 4 INC Supply voltage controller for incandescent lamps PCD 300 o4a
DT 5 CONF conversion from digital signal into d.c. voltage
DT 6 LED LED modules (Converter) LCAI
DT 7 SOMFY Relais Somfy
DT 8 Colour Tunable Wite
DT 9 Sequenzer
Addressing and grouping_
Scenes_
Sequences_
Schedules (SDL)_
Schedule list (SDLL)_
I NOTICE
You can assign names for groups, scenes, sequences and schedules to facilitate programming and operating
steps (see " ").Assigning names, p. 49
