3.1. Operation
The x/e-touchPANEL can be operated in two different ways:
The operation differs as follows:
The connection between PC and the x/e-touchPANEL is done via .Ethernet interface, p. 99
3.2. Used software
The x/e-touchPANEL is run by an integrated software called "xetouch". A combination with control gear of the
comfortDIM series is possible.
3.2.1. Used navigational symbols
For navigation within the software different symbols are used. Which symbols are displayed depends on the
selected settings.
The most important symbols are explained below:
Symbol Naming
Home menu
Main menu
"Time & Date" menu
Previous page and next page
via the integrated touchpanel_
via a PC (which must be connected to the x/e-touchPANEL)_
The integrated touchpanel is operated by touching the touchscreen with a finger_
The PC is operated with a keyboard or a mouse (which must be connected to the PC)_
